Magnum 4K8 Switches
1.2

Ordering Information

MODEL
Magnum 4K8
Magnum 4K8R
Fiber Port Modules for Magnum 4K-Series(4K8 Switches only)
FPM-MSC
FPM-MST
FPM-SSC
FPM-MV45
FPM-MTRJ
K8PM-RJ45
FPM10-MST
FPM-BLNK
See appendices B and C for information on DC-powered models and options.
GarrettCom, Inc. reserves the right to change specifications, performance
characteristics and/or model offerings without notice.
www GarrettCom com
.
Installation and User Guide
Magnum 4K8 Switches
DESCRIPTION
Ethernet Switch with 8 RJ-45 ports, each auto-sensing for
10Mbps/10Mbps FDX/HDX operation. Optional fiber port
may be configured from the family of modules below.
Each port is switched and provides a full-speed traffic
domain with non-blocking performance. Includes internal
auto-ranging power supply, cooling fan, and metal brackets
for rack-mounting. LEDs and user ports are in the front,
power inputs is in the rear. Units with -48V power supply
options available
"Reverse" model, Same as Model 4K8 Switch except user
ports and the power input connectors are in the rear.
Fiber module for 4K8 Switches, with 100Mbps multi-mode
FX SC connectors
Fiber module for 4K8 Switches, with 100Mbps multi-
mode FX ST connectors
Fiber module for 4K8 Switches, with 100Mbps single-
mode FX SC connectors
Fiber module for 4K8 Switches, with 100Mbps multi-
mode FX "VF-45" connectors
Fiber module for 4K8 Switches, with 100Mbps multi-
mode FX "MTRJ" connectors
RJ-45 module for 4K8 Switches, with 100Mbps fixed RJ-
45 ports, full or half-duplex
Fiber module for 4K8 Switches, with 10 Mbps multi-mode
FL ST-type connectors
Blank face plate, included in 4K8 switch unit when no fiber
port option is selected
.
3
(10/04)
