RESET
Resets PIP options back to factory settings except SUB INPUT and ASPECT.

OSD

LANGUAGE
Select the language used by the OSD.
ENGLISH
DEUTSCH
FRANÇAIS
ITALIANO
ESPAÑOL
SVENSKA
РУССКИЙ
MENU DISPLAY TIME
Turns off the OSD after a period of inactivity. The preset choices are 10-240 seconds.
OSD POSITION
Determines the location where the OSD appears on the screen.
UP
DOWN
RIGHT
LEFT
INFORMATION OSD
Selects whether the information OSD is displayed or not. The information OSD will be displayed
when the input signal or source changes. The information OSD will also give a warning when
there is no-signal or the signal is out-of range.
An interval between 3 to 10 seconds for the Information OSD to appear is available.
MONITOR INFORMATION Indicates the model and serial number of your monitor and fi rmware version.
CARBON SAVINGS: Display the estimated carbon saving information in kg-CO2. The carbon
footprint factor in the carbon saving calculation is based on the OECD (2008 Edition).
CARBON USAGE: Display the estimated carbon usage information in kg-CO2. This is the
arithmetic estimation, not actual measurement value. This estimation is based without any
options.
OSD TRANSPARENCY
Set the transparency of the OSD.
OSD ROTATION
Determines the OSD display direction between landscape and portrait.
LANDSCAPE
Display the OSD with landscape mode.
PORTRAIT
Display the OSD with portrait mode.
INPUT NAME
You can create a name for the INPUT currently being used.
Max: 8 characters, including Space, A-Z, 0-9, and some symbols.
MEMO
Sets a title and message via HTTP server. See page 42.
RESET
Resets the following settings within the OSD menu back to factory setting:
MENU DISPLAY TIME, OSD POSITION, INFORMATION OSD, OSD TRANSPARENCY.

MULTI DISPLAY

ID CONTROL
Sets the monitor ID number from 1-100 and group ID from A-J. DETECTED MONITORS shows
the number of all monitors which follow in the chain with LAN.
NOTE: Group ID is made of multiple selections.
AUTO ID
When "YES" is selected, monitor ID numbers are set automatically in all monitors which follow in
the chain with LAN.
NOTE: All monitors which follow in the chain with LAN should be ON. When executing this
function while in standby mode or power save mode, "LAN POWER" should be ON.
AUTO ID RESET
Resets monitor ID number of all monitors which follow in the chain with LAN.
NOTE: AUTO ID RESET should be done when changes the number of monitors which follow in
the chain with LAN.
IR LOCK SETTING
Selects the mode of the monitor for use with the infra-red remote control.
Selects "LOCK" to prevent the monitor from being controlled by the wireless remote controller. To
return to normal operation, press the "DISPLAY" button on the remote controller for 5 seconds.
English-23
-
ENGLISH
(Depends on
destination)
30 SEC.
X = 128, Y = 225
ON, 3 SEC.
-
OFF
LANDSCAPE
-
-
-
1
NO
NO
UNLOCK
