BASS
SURROUND
PIP AUDIO
LINE OUT
AUDIO INPUT
RESET

SCHEDULE

OFF TIMER
SCHEDULE SETTINGS
SCHEDULE LIST
DATE & TIME
YEAR
MONTH
DAY
TIME
DAYLIGHT SAVING
RESET

PIP

KEEP PIP MODE
PIP MODE
OFF
PIP
POP
PICTURE BY PICTURE-
ASPECT
PICTURE BY PICTURE-
FULL
SUB INPUT
PIP SIZE
PIP POSITION
ASPECT
TEXT TICKER
MODE
POSITION
SIZE
BLEND
DETECT
FADE IN
*1: This function depends on which option board you use.
To accentuate or reduce the low frequency sound.
Press + button to increase BASS sound.
Press - button to decrease BASS sound.
Artifi cial surround sound.
NOTE: Audio out is disabled when this function is set to ON.
Selects source of PIP audio.
Selecting "VARIABLE" enables control of the line out level with the VOLUME button.
NOTE: Audio out is disabled when this function is set to ON.
Selects audio input source [IN1], [IN2], [IN3]*
1
1
[DPORT2]*
, [DPORT3]*
.
Resets "AUDIO" options back to factory settings except VOLUME.
Sets the monitor to power off after a length of time.
A time between 1 to 24 hours is available.
Creates a working schedule for the monitor to use.
List of schedules.
Sets the date, time, and daylight saving region. Date & time must be set in order for the
"SCHEDULE" function to operate. See page 29.
Confi gures the year for the real-time clock.
Confi gures the month for the real-time clock.
Confi gures the day for the real-time clock.
Confi gures the time for the real-time clock.
Confi gures daylight savings on or off.
Resets the following settings within the SCHEDULE menu back to factory setting: OFF TIMER,
SCHEDULE SETTINGS.
Allows the monitor to remain in "PIP" and "TEXT TICKER" mode after powering off.
When Power is returned, PIP and TEXT TICKER appear without having to enter the OSD.
Selects Picture-in-Picture mode.
NOTE: This function is released when selecting IMAGE FLIP except for NONE.
Normal mode.
Picture in Picture mode.
Picture out Picture mode.
Picture by picture (split screen) mode, with keep aspect.
Picture by picture (split screen) mode, with full screen.
Selects sub picture input signal.
Determines the size of the sub-picture used in Picture-in-Picture (PIP) mode.
Press the SET/POINT ZOOM button to adjust. Press + or CH+ to expand. Press - or CH- to
reduce.
It is also possible to change the sub-picture size by pressing the SET/POINT ZOOM button when
the sub-picture is shown.
Determines the location where the PIP appears on the screen.
Selects sub picture aspect, [FULL], [NORMAL] and [WIDE]. See page 17.
Enables Text Ticker and allows you to set Horizontal or Vertical direction.
Selects the location of the Text Ticker on the screen.
Determines the size of the Text Ticker in relationship to the overall screen size.
Sets the transparency of the Text Ticker (0: transparent, 100: opaque).
Enables auto-detection of the Text Ticker.
Enables fade-in of the text ticker.
1
, [OPTION]*
1
, [HDMI], [DPORT], [HDMI2]*
English-22
0
OFF
MAIN AUDIO
FIXED
1
,
Depend on
signal input
-
OFF
-
-
-
-
-
-
OFF
-
OFF
OFF
Depends on
signal input
37
X = 95, Y = 92
FULL
OFF
