ADVANCED OPTION2

AUTO DIMMING
AUTO BRIGHTNESS
DPORT, DVI, VGA, RGB/HV*
1
, DPORT2*
1
,
1
DPORT3*
inputs only
ROOM LIGHT
SENSING
HUMAN SENSING*
2
DISABLE
AUTO OFF
CUSTOM
INTELLI. WIRELESS DATA Select "ON" to activate INTELLIGENT WIRELESS DATA function (see page 44). A password is
RESET
FACTORY RESET
*1: This function depends on which option board you use.
*2: The function is available only when connecting the optional control unit.
Adjusts the backlight of the LCD automatically depending on the amount of ambient light.
Adjusts the brightness level according to the input signal.
NOTE: Do not select this function when ROOM LIGHT SENSING is MODE1 or MODE2.
The backlight of the LCD screen can be set to increase or decrease depending on the amount of
ambient light within the room. If the room is bright, the monitor becomes correspondingly bright. If
the room is dim, then the monitor will dim accordingly. The purpose of this function is to make the
viewing experience more comfortable to the eye in a variety of lighting conditions.
NOTE: When ROOM LIGHT SENSING is set to MODE1 or MODE2, BACKLIGHT, AUTO
BRIGHTNESS and BACKLIGHT in SCREEN SAVER function are disabled.
Do not cover the room light sensing sensor when you use MODE1 or MODE2.
AMBIENT parameter setting
ROOM LIGHT SENSING in OSD, select MODE1 or MODE2 and set MAX LIMIT, IN BRIGHT and
IN DARK in each mode.
MAX LIMIT: This is the max level of backlight which you set.
IN BRIGHT: This is the backlight level that the monitor will go up to when the ambient light level is
highest.
IN DARK: This is the level of backlight that the monitor will go down to when the ambient light
level is low.
When the ROOM LIGHT SENSING is enabled the Backlight level of the screen changes
automatically according to the lighting conditions of the room (see fi gure below).
BACKLIGHT level set for
the monitor to use when
ambient lighting level is
low.
MAX LIMIT: BACKLIGHT level is limited to your set level.
IN DARK: BACKLIGHT level set for the monitor to use when ambient lighting level is low.
IN BRIGHT: BACKLIGHT level set for the monitor to use when ambient lighting level is high.
HUMAN SENSING has three settings.
NOTE: POWER SAVE is disabled when AUTO OFF or CUSTOM is selected in HUMAN
SENSING.
No human sensing.
At the preset time, when no person is detected, BACKLIGHT and VOLUME automatically go
into OFF. When a person comes near the monitor again, the monitor will automatically return to
normal mode.
BACKLIGHT and VOLUME automatically shift to the set value when detecting no person. When
a person comes near the monitor again, the monitor automatically return to normal mode and
display the input signal selected in INPUT SELECT.
required when using the function.
Resets "ADVANCED OPTION 2" settings back to factory setting, except for INTELLI. WIRELESS
DATA.
Resets OSD options back to factory settings EXCEPT FOR: PICTURE MODE, VOLUME,
SCHEDULE SETTINGS, DATE & TIME, DAYLIGHT SAVINGS, SUB INPUT in PIP, ASPECT
in PIP, LANGUAGE, OSD ROTATION, MEMO, POWER ON DELAY, CHANGE PASSWORD,
SECURITY, IP ADDRESS SETTING, LAN POWER, PING and LONG CABLE COMP.
Factory Setting
IN DARK
IN BRIGHT
room bright condition
dark
bright
Screen Backlight value by MODE1
Screen Backlight value by MODE2
English-28
BACKLIGHT range
BACKLIGHT range when
set to MAX LIMIT.
BACKLIGHT level set
for the monitor to use
when ambient lighting
level is high.
-
OFF
OFF
DISABLE
-
-
-
ON
-
-
