CONTENTS 1. INTRODUCTION..........................4 1-1 Features ............................... 4 1-2 Compliance ............................5 2. UNPACKING THE BALANCE ......................6 2-1 Unpacking ............................6 2-2 Installing the Balance ........................... 8 3. PRECAUTIONS ..........................10 3-1 Before Use ............................10 3-2 When Building into a System ......................11 3-3 During Use ............................
Page 4
10. FUNCTION TABLE ........................28 10-1 Structure and Sequence of the Function Table ................28 10-2 Display and Keys ..........................28 10-3 Details of the Function Table ......................29 10-4 Description of the Class “Environment, Display” ................33 10-5 Description of the Item “Data output mode” ..................35 10-6 Description of the Item “Data format”...
Page 5
18. COMMANDS..........................68 18-1 Command List ..........................68 18-2 Acknowledge Code and Error Codes ....................69 18-3 Control Using CTS and RTS ......................70 18-4 Settings Related to RS-232C ......................70 19. BCD OUTPUT (OP-01) .........................71 19-1 Connector Pin Nos. and Specifications .................... 71 20.
The weighing unit is compact, with a width of 80 mm. High Resolution and High Response Speed Model Weighing capacity Minimum weighing value Stabilization time *1 AD-4212A-100 110 g 0.1 mg 1.1 to 1.3 seconds AD-4212A-200 210 g 0.8 to 1.0 second...
Stainless Steel Casing with high chemical resistance for the AD-4212B weighing unit Stainless Steel Breeze Break, provided for the AD-4212B series balance and the AD-4212A-100, for more accurate weighing. For the other models, it is available as an option (OP-19).
See the illustrations to confirm that everything is contained. Stainless steel breeze break Provided for the AD-4212B series balance and the AD-4212-100. For the other models, available as an option (OP-19). AD-4212A-100/200 AD-4212B-23/101/102 AD-4212A-600/1000 AD-4212B-201/301 Weighing Weighing...
Page 9
Accessories Windows communication Calibration weight tools (WinCT) OIML, Class E2 or equivalent (AD-4212B-23 only) Weight Model AD-4212B-23* AD-4212A-100 Mounting fixture (2 pcs.) AD-4212B-101/102 AD-4212A-200 100g AD-4212B-201/301 Screw and washers AD-4212A-600/1000 200g to attach the mounting fixture (3 sets) AC adapter D-Sub 25-pin connector To mate with the I/O unit.
(AD-4212B-23/101/102 only), the pan support and the weighing pan on the weighing unit. The stainless steel breeze break is provided for the AD-4121B series balance and the AD-4212A-100 as a standard accessory, and for the other models as an option. Use it as necessary when performing calibration or checking accuracy.
Page 11
Rear of the weighing unit Arrow mark face up Serial number Make sure the weighing unit, display unit and connection cable have the same serial number. Connection cable Rear of the display unit How to disconnect the cable from the weighing unit Slide the connector sleeve in the direction of the arrow to unlock and gently pull the connector out.
3. PRECAUTIONS To get the optimum performance from the balance and acquire accurate weighing data, note the following: 3-1 Before Use Install the balance in an environment where the temperature and humidity are not excessive. The best operating temperature is about 20°C / 68°F at about 50% relative humidity. Install the balance where it is not exposed to direct sunlight and it is not affected by heaters or air conditioners.
3-2 When Building into a System The AD-4212A/B is a precision balance. When it is built into a system and used, errors such as unstable weight values may occur due to static electricity, vibration and materials used for the devices near the balance. When using the balance that is built into a system, take the following precautions.
Page 14
Apply an anti-static agent onto plastic. When an operator is static charged If an operator’s clothes are static charged, especially in winter, it may be a cause for unstable weight values. Wear an anti-static wrist strap. Errors due to air flow Where the influence of ambient air flow is great such as: close to an air conditioner, door or passage way.
Magnetic material The balance uses a strong magnet as part of the balance assembly, so use much care when weighing magnetic materials. Place a non-magnetic object such as aluminum or brass between the sample and the balance, also keep an appropriate distance between them while weighing. 3-3 During Use To minimize the affect by electrical noises, earth ground the weighing unit and the display unit.
4. DISPLAY SYMBOLS AND KEY OPERATION Key operation Key operation affects how the balance functions. The basic key operations are: “Press and release the key immediately” or “Press the key” = normal key operation during measurement “Press and hold the key” Display symbols ・Displays memory data information Weighing speed indicators...
5. WEIGHING UNITS 5-1 Units With the AD-4212A/B series balance, the following weighing units and weighing modes are available: Counting mode Percent mode Programmable-unit (AD-4212A only) A unit or mode can be selected and stored in the function table as described in “5-2 Changing the Unit”. If a weighing mode (or unit of weight) has been turned off, that mode or unit will be missing in the sequence.
Page 18
The table below indicates the weighing capacity and the minimum display for each unit, depending on the balance model. AD-4212A-100 AD-4212A-200 AD-4212A-600 AD-4212A-1000 Unit Capacity Minimum Capacity Minimum Capacity Minimum Capacity Minimum display display display display Gram 0.0001 0.001 0.001 1100 0.001...
6. WEIGHING 6-1 Basic Operation (Gram Mode) 1 Plug in the AC adapter. (Software version display) 2 Press the ON:OFF key to display the weighing mode. (The decimal point position depends on the balance model.) Notes The auto display-ON function is available to display the weighing mode without the key operation when the AC adapter is plugged in.
6-2 Smart Range Function The AD-4212B-101 is equipped with two ranges. The precision range has a higher resolution. The standard range has normal resolution. The range switches automatically, depending on the value displayed. Pressing the RE-ZERO key allows weighing in the precision range, regardless of the tare value. The minimum weighing value can be fixed to 0.1 mg or 1 mg by pressing the SAMPLE key.
7. CHANGING THE WEIGHING SPEED The weighing speed can be selected from the following three rates to minimize the influence on weighing that is caused by drafts and/or vibration at the place where the balance is installed. Weighing speed indicators Indicator Parameter Speed...
8-1 Calibration This function calibrates the balance using the calibration weight. (Display example: AD-4212B-102) Operation 1 Plug in the AC adapter and warm up the balance with nothing on the pan. • AD-4212A series balance: 30 minutes or more Press and hold the key •...
Page 25
From previous page 5 Confirm that there is nothing on the pan and press the PRINT key. The balance measures the zero point. Do not allow vibration or drafts to affect the balance. The balance displays the calibration weight value. 6 Place a calibration weight, of the weight value displayed, on the pan and press the PRINT key.
8-2 Calibration Test This function tests the balance weighing accuracy using the calibration weight and outputs the result. This is available only when the “GLP output (info)” parameter is set to “1” or “2”. (Calibration test does not perform calibration. Display example: AD-4212B-102) Operation 1 Plug in the AC adapter and warm up the balance with nothing on the pan.
Page 27
From previous page 5 Confirm that there is nothing on the pan and press the PRINT key. The balance measures the zero point and displays the measured value. Do not allow vibration or drafts to affect the balance. The balance displays the calibration weight value. 6 Place a calibration weight, of the weight value displayed, on the pan and press the PRINT key.
9. FUNCTION SWITCH AND INITIALIZATION 9-1 Permit or Inhibit The balance stores parameters that must not be changed unintentionally (e.g. Calibration data for accurate weighing, data for adapting to the operating environment, control data for the RS-232C interface). There are two switches for protecting the parameters. The switches can select either “permit”...
9-2 Initializing the Balance This function returns the following parameters to factory settings. Calibration data Function table Upper/lower limit values The sample unit mass value (counting mode), 100% reference mass value (percent mode) The data that is stored in the balance using the data memory function Calibration weight value Function switch settings Note...
10. FUNCTION TABLE The function table reads or rewrites the parameters that are stored in the balance. These parameters are maintained in non-volatile memory, even if the AC adapter is removed. 10-1 Structure and Sequence of the Function Table The function table menu consists of two layers. The first layer is the “Class” and the second layer is the “Item”.
10-3 Details of the Function Table Class Item and Parameter Description Fast weighing speed, sensitive value FAST Factory setting Cond 2: AD-4212B-23 MID. Condition 1: Other models Slow weighing speed, stable value SLOW Stable range is ±1 digit The stabilization indicator 5t-b illuminates when the display Stability band width...
Page 32
Class Item and Parameter Description Cpout Cp-t Only the AD-4212B series 3-level comparator contact output Comparator Comparator output balance displays this class and 5-level comparator contact output item. output setting No comparison Comparison, excluding “near zero” when stable or overloaded Comparison, including “near 0: AD-4212B-23 zero”...
Page 33
Class Item and Parameter Description Displayed value>Reference Plus only ap-p Displayed value<Reference Minus only Auto print polarity Regardless of displayed value Both 10 digits ap-b Difference between reference 100 digits Auto print difference value and displayed value 1000 digits Not used Stores unit mass in counting mode data Related items:...
Page 34
Class Item and Parameter Description 600 bps 1200 bps 2400 bps Baud rate 4800 bps 9600 bps 19200 bps 7 bits, even btpr Serial 7 bits, odd Data bit, parity bit interface 8 bits, none Crlf CR: ASCII code 0Dh CR LF Not displayed LF: ASCII code 0Ah...
10-4 Description of the Class “Environment, Display” Condition ( Cond Cond 0 This parameter is for sensitive response to the fluctuation of a weight value. Used when fast weighing speed is required. After setting, the balance displays FAST. Cond 2 This parameter is for stable weighing with slow response.
Page 36
Zero tracking ( trc ) This function tracks zero point drift caused by changes in the environment and stabilizes the zero point. Three levels of zero tracking are available. When the weight value is only a few digits, turn the function off for accurate weighing.
Tare at start ( p-tr ) When a hopper is attached to the weighing pan and loss-in weighing is performed, the remaining amount of the material will become unknown if tare is performed each time a weighing starts. When "p-tr 0" is selected, tare is not performed at weighing start. So, the remaining amount of the material can be monitored when the power is turned on.
Caution The balance may not transmit the data completely at the specified refresh rate, depending on the baud rate or data added to the weighing data such as time, date or ID number. Key mode B When the PRINT key is pressed or the external PRINT contact input is used, the balance outputs or stores the weighing data immediately regardless of the display condition.
Page 39
DP (Dump print) format 5if type 1 This format is used when the peripheral equipment can not receive the A&D format. If an AD-8121B is used, set the printer to MODE 3. This format consists of sixteen characters excluding the terminator. A header of two characters indicates the balance condition.
5if type 5 CSV format This format separates the data of A&D standard format and the unit by a comma ( , ). This format outputs the unit even when the data is overloaded. When a comma ( , ) is selected for decimal point, separators are set to semicolon ( ; ). When the ID number, data number, time and date are added at "Data output (dout)"...
10-9 Clock and Calendar Function The balance is equipped with a clock and calendar function. When the “GLP output (info)” parameter is set to “1” or “2” and the “Time/Date output (5-td)” parameter is set to “1”, “2” or “3”, the time and date are added to the output data.
Page 43
Confirming the date 6 The current date is displayed with all the digits blinking. To change the display order of year (y), month (n) and day (d), press the MODE key. The date is output in the order as specified. When the date is correct and the operation is to be finished, press the CAL key and proceed to step 8.
10-10 Comparator Function The balance outputs the results of the comparison in three or five levels. AD-4212A series balance: 3-level output (standard) or 5-level output when OP-04 is installed. AD-4212B series balance: 3-level or 5-level output, switched by “Comparator output setting (Cp-t)”...
Page 45
Five-level comparison Contact output Comparison Display Buzzer results HH blinking short open open open open open short open open open HI illuminated OK illuminated open open short open open open open open short open LO illuminated LL blinking open open open open short...
Page 46
Confirming the upper/lower limit values To confirm the upper/lower limit values during weighing operation, press the MODE key. The upper/lower limit values will be displayed. Even under this condition, weighing operation goes on and data output, contact output of the comparison results and RE-ZERO can be performed. When three-level comparison is selected Weighing mode Comparison OK...
Page 47
Note The upper/lower limit values can be confirmed by external commands using the RS-232C serial interface. e.g., Command (to confirm secondary upper limit value) Response HH, +100.00000 (secondary upper limit value=100.00000 g) Command (to confirm upper limit value) Response HI +080.00000 (upper limit value=80.00000 g) Command (to confirm lower limit value)
11. ID NUMBER AND GLP REPORT The ID number is used to identify the balance when Good Laboratory Practice (GLP) is used. The ID number is maintained in non-volatile memory even if the AC adapter is removed. The GLP output format is selected at “GLP output (info)” of the function table and can be output to a personal computer or printer using the RS-232C serial interface.
11-2 GLP Report Set the following parameters to output the report. To print the report, set the “GLP output ( info )” parameter to “1” and use MODE 3 of the AD-8121B. For details on using the printer, refer to “17-1 Connection to the AD-8121B Printer”. To output the report to a personal computer using the RS-232C interface, set the “GLP output ( info )”...
Calibration test report using an external weight (Calibration test does not perform calibration.) When the setting is “info 1”: When the setting is “info 2”: General data format AD-8121 format Manufacturer A & D <TERM> A & D Model A D 4 21 2 B - 10 2 <TERM> ...
Page 51
Title block and end block When weight values are recorded as GLP data, a “Title block” is inserted at the beginning and an “End block” is inserted at the end of a group of weight values in the GLP report. Notes To output the report to an AD-8121B , use MODE 3 of the AD-8121B.
Automatic Counting Accuracy Improvement (ACAI) function to improve the counting accuracy. Notes Use samples with a unit mass of 1 mg or more (AD-4212A-100, AD-4212B series) or 10 mg or more (AD-4212A-200/600/1000) for counting. If the sample unit mass variable is too large, it may cause a counting error.
Page 53
Notes If the balance judges that the mass of the samples is too light and is not adequate to be used as the unit mass, it displays 1lo . In that case, store the mass by some quantity. For example, when the model with the minimum weighing value of 0.01 g is used and 10 pieces of samples weigh 0.05 g.
100% reference Minimum Models 100% reference Minimum (A series) mass weighing value (B series) mass weighing value AD-4212A-100 0.0100g to 0.0999g AD-4212B-23 0.00100g to 0.00999g 0.1000g to 0.9999g 0.1% 0.01000g to 0.09999g 0.1% 1.0000g or greater 0.01% 0.1000g or greater 0.01%...
14. DATA MEMORY Data memory is a function to store weighing data or calibration data to display or output later. The data memory function can also store multiple upper/lower limit values or unit mass values, for later selection as necessary. One of the following data sets can be stored: Weighing data (Up to 200 sets.
14-2 Memory for Weighing Data The data memory function can store 200 sets of weighing data (100 set if time and date are added). Even if the AC adapter is removed, the data is maintained in non-volatile memory. It is not necessary that the printer or computer be continually connected to the balance, because the balance stores the weighing data in memory.
Page 57
The following commands can not be used during data storage. Query command for weighing data. Query command for stable weighing data. Query command for weighing data. Query command for continuous weighing data. Setting the function table Parameter settings for each output mode are as follows: Item Data output Auto...
Page 58
Transmitting all memory data at one time Confirm that the “Serial interface ( 5if )” parameters are set properly. For details, refer to “10. FUNCTION TABLE” and “17. CONNECTION TO PERIPHERAL EQUIPMENT”. 1 Press and hold the PRINT key until reCall is displayed, then release the key. out .
14-3 Memory for Calibration and Calibration Test Data Calibration data (when and how it is performed) and calibration test data can be stored in memory. All the data in memory is available to be output at one time to a printer or personal computer. Up to 50 data sets of the latest calibration or calibration test can be stored.
14-4 Memory for Unit Mass in the Counting Mode The data memory function can store 20 sets of unit mass for the counting mode. Even if the AC adapter is removed, the data is maintained in non-volatile memory. Among the 20 sets, “p01” is the memory function for the standard counting mode.
14-5 Memory for Upper/lower limit values Upper/lower limit values stored in memory can be selected easily by pressing the MODE key. Storage capacity for the 3-level comparison is 20 sets of upper/lower limit values (code numbers C01-C20). "C01" is to store the upper and lower limit values that are set in the function table.
Page 62
Inputting the upper/lower limit values (3-level comparison) Upper/lower limit value code 1 Display the weighing mode. 2 Press and hold the PRINT key until the balance enters the upper/lower limit value selection mode as shown below. Display example The upper limit value of the currently selected code is displayed. 3 Select the code and upper/lower limit values to be used using the following keys.
Page 63
Switching the upper/lower limit values (3-level comparison) 1 Display the weighing mode. Upper/lower limit value code Weighing mode 2 Press the MODE key to select the upper/lower limit value code. Code C01 Upper limit value Code C01 Lower limit value Code C02 Upper limit value Code C02...
A coefficient of 1 was set at the factory. Model Minimum coefficient Maximum coefficient AD-4212A-100 10000 0.000001 AD-4212A-200/600/1000 1000 Operation 1 Press and hold the SAMPLE key until ba5fnc of the function table is displayed, then release the key.
16. I/O UNIT SPECIFICATIONS (Standard interface) 16-1 RS-232C/Comparator Contact Output/External Contact Input D-Sub 25 pin numbers D-Sub 25 pin assignments Pin No. Signal name Interface type Direction Description Frame ground RS-232C Input Receive data RS-232C Output Transmit data RS-232C Input Ready to send RS-232C Output...
Page 66
Balance (DCE) Personal computer (DTE) example Use a shielded cable. Of DOS/V type Balance interior (D-Sub9) (Cable shield) Connector shell Pin 3 Pin 2 Pin 7 Pin 8 Pin 6 Pin 5 Use a shielded Comparator contact ratings cable. Maximum contact voltage 100VDC (Cable shield) Maximum contact current...
17. CONNECTION TO PERIPHERAL EQUIPMENT 17-1 Connection to the AD-8121B Printer Set the following parameters to use the AD-8121B printer. Factory AD-8121B Class Item setting Mode 1 Mode 2 Mode 3 0, 1, 2, 4, 5 0, 1, 2, 4, 5 Data output mode ap-p Auto print polarity...
17-2 Connection to a Computer The AD-4212A/B series balance is of the DCE type (Data Communication Equipment), which can be connected to a personal computer using the RS-232C interface. Before connection, read the personal computer manual thoroughly. Use a standard DCE cable for connection (cable type: straight through). 17-3 Using Windows Communication Tools (WinCT) When Windows is used as an operating system in a personal computer, the provided WinCT software can be used to transmit the weighing data to the personal computer.
Page 69
Using the WinCT software, the balance can do the following: 1 Analyzing the weighing data and the statistics with “RsKey” The weighing data can be input directly into an Excel worksheet. Then, Excel can analyze the data to obtain total, average, standard deviation, maximum and minimum value, and display them in a graph.
18. COMMANDS 18-1 Command List Commands to query weighing data Cancels the S or SIR command. Requests the weighing data immediately. Requests the weighing data when stabilized. Requests the weighing data immediately. Requests the weighing data continuously. Commands to control the balance Same as the CAL key.
18-2 Acknowledge Code and Error Codes When the “Serial interface function ( 5if )” parameter is set to “erCd 1”, the balance outputs <AK> code or error code to each command as follows: <AK> (06h) Acknowledge in ASCII code. When the balance receives a command to request data and can not process it, the balance transmits an error code (EC, Exx).
18-3 Control Using CTS and RTS Depending on the “Ct5” parameter of “Serial interface ( 5if )”, the balance performs as follows: Ct5 0 Regardless of whether the balance can receive a command or not, the balance keeps the CTS line HI. The balance outputs data regardless of the condition of the RTS line.
19. BCD OUTPUT (OP-01) Weighing data will be output in BCD, in sync with the display refreshing. In addition, the polarity (+/-) and balance condition (stable/not stable, overload(positive/negative)) will be output. The strobe signal allows inputting data easily. Inputting BUSY will hold data or prevent data that is being output from being rewritten.
Page 74
Pin assignments and I/O logic Output pin assignments Input pin assignments Pin No. Signal Pin No Signal BUSY RE-ZERO Switch ON/OFF Input signal GND Not used (Reserved) ・The pins, which are not specified, have no connection. (Pins 2, 4, 6, 8, 10, 36. 38) Output logic Factory settings When...
Page 75
OP-01 installation procedure 1 Remove the two screws that secure the I/O unit to OP-01 the rear of the display unit. 2 Remove the I/O unit and disconnect the two cable connectors. 3 Connect the 14-pin cable connector that was removed in step 2 to the OP-01 connector.
20. EXTENDED FUNCTIONS (AD-4212A only) The AD-4212A series balance has several extended functions equipped for special applications or to troubleshoot when using the standard functions. Some settings of the extended functions may affect the weighing accuracy. Therefore, they are set to disabled at the factory when shipped.
20-1 Description of "Averaging range" and "Averaging time" Averaging range ( ) and averaging time ( f1-b f1-t 1. When the fluctuation of a weight value is beyond the range that is selected in "f1-b", the averaging operation is disabled and the display reflects the varying value. 2.
21. MAINTENANCE Do not disassemble the balance. Contact the local A&D dealer if the balance needs service or repair. Use the original packing material for transportation. Do not use organic solvents to clean the balance. Clean the balance with a lint free cloth that is moistened with warm water and a mild detergent.
Page 80
When the balance is built into a system, remove the balance from the system. Place it on a solid table. Install the breeze break and perform checking. When the balance proper performance is confirmed, refer to page 10 to set up the installation site.
22-2 Error Codes Display Error code Description Weighing unit connection error The weighing unit is not connected to the display properly. Refer to “2-2 Installing the Balance” to perform a proper connection. Internal error Indicates an internal error as the result of self-check function.
Page 82
Display Error code Description Unit mass error The sample unit mass for the counting mode is too light. Storing and using it for counting will cause a counting error. Add samples to reach the specified number and press the PRINT key. Pressing the PRINT key without adding samples will shift the balance to the counting mode.
Display Error code Description EC, E03 Timeout error If the timeout parameter is set to “t-Up1”, the balance did not receive the next character of a command within the time limit of one second. Confirm the communication. EC, E04 Excess characters error The balance received excessive characters in a command.
OP-08 Ethernet interface (RS-232C and comparator contact output disabled) OP-19 Stainless steel breeze break (Provided as standard for AD-4212A-100) OP-20 Metal leveling foot Only one extension cable can be used. The maximum distance between the weighing unit and the display unit is 5 m (connection cable 2 m + extension cable 3 m).
Page 85
AD-4212B-23 AD-4212B-101 AD-4212B-102 AD-4212B-201 AD-4212B-301 Weighing capacity 21 g 110 g / 31 g*1 110 g 210 g 310 g Maximum display 110.0084 g / 21.000084 g 110.00084 g 210.0084 g 310.0084 g 31.00009 g*1 Minimum weighing value 0.1 mg / 0.001 mg 0.01 mg 0.1 mg...
A weighing pan specially designed for the balance can be installed. Design the weighing pan as described below: Using the pan support The pan support can be removed. AD-4212B-23/101/102 AD-4212A-100/200 Special weighing pan (Example) AD-4212B-201/301 Weighing Two points on the center...
Page 87
Using the pan boss The pan boss can not be removed. Approx. 16mm Three point M3 screw Length 4 mm or less 7.5mm 19.5mm Approx. 17.8mm Pan support (Can be removed) Front Special weighing pan Back (Example) Weighing unit Weighing unit Pan boss (Can not be removed)
Page 88
Design the weighing pan so that the mass falls in the ranges shown in the table below: Mass of Model State special weighing pan (g) AD-4212A-100 Pan support is used (with weighing pan removed) 20 to 70 Pan boss is used (with the weighing pan and pan 60 to 110...
Page 89
AD-4212A-600 When the weighing pan and When the weighing pan, pan support plate pan support plate are removed and pan support are removed 210 g Mass range to be weighed 210 g Mass range to be weighed 610 g 610 g 550 g 510 g 150 g...
Page 90
Mass of the special weighing pan (AD-4212B series balance) Design the weighing pan so that the mass falls in the ranges shown in the table below: Mass of Model State special weighing pan (g) AD-4212B-23 Pan support is used (with weighing pan removed) 5 to 20 Pan boss is used (with the weighing pan and pan 30 to 45...
Page 91
AD-4212B-201 When the weighing pan When the weighing pan and is removed pan support are removed 110 g 110 g Mass range Mass range to be weighed to be weighed 210 g 210 g 120 g 160 g Mass Mass of special of special 20 g...
25. INSTALLING THE DISPLAY UNIT Installing the display unit on a wall using the standard stand 1. Secure the stand, that is attached to the display unit, on the wall using the four screws 2. Adjust the angle of the display unit and tighten the angle adjustment knobs located on both sides of the display unit.
26. ATTACHING THE MOUNTING FIXTURES The mounting fixtures provided with the AD-4212A/B series balance are used to secure the weighing unit from above in a determined position, when the weighing unit is built into a system. To attach the fixtures to the weighing unit, use the screw holes after the three leveling feet are removed from the bottom of the AD-4212A/B series balance weighing unit.
Display unit Weighing unit (Bottom) Same for all the models Screw part M6XP0.75 (98) Depth 20mm Weighing unit AD-4212A-100/200 AD-4212B-23/101/102 AD-4212B-201/301 Height up to the pan boss Height up to the pan boss (98) (98) Unit: mm * Adjustable range...
Page 95
AD-4212A-600/1000 Height up to the pan boss * Adjustable range (98) Weighing unit with the mounting fixtures attached (90) Unit: mm...
28. OPTIONS AD-8121B Printer Compact thermal dot-matrix printer Statistical function, clock and calendar function, interval print function, graphic print function, dump print mode 5 x 7 dots, 16 characters per line Print paper (AX-PP143, 45 (W) x 50 (L) mm , ø65 mm) AC adapter or alkaline battery.
Page 97
When building into a system, use the Ethernet interface (OP-08). OP-19: Stainless steel breeze break Provided as a standard accessory for the AD-4212B series balance and AD-4212A-100 Sold separately as an option (OP-19) for the other models OP-20: Metal leveling foot It is possible to remove the plate from the screw.
29. TERMS/INDEX Terms Stable value The weight data when the stabilization indicator appears. Environment Ambient conditions such as vibration, drafts, temperature, static electricity or magnetic fields which affect the weighing operation. Store To save the weighing data, unit mass, calibration data or upper/lower limit values using the data memory function.
Page 100
Number of samples........82, 83 Numerical format .........37 Capacity indicator ....29, 34 GLP report........21, 46, 47 Gram mode ..........18 - O - ..........4, 42, 43 - H - ON/OFF key ...... 14, 18, 26, 34, 68 OP-01 BCD output/External contact input ..94 ..........
Page 101
5-id Unit ID number output....31, 38 Unit ...........32 SLOW ............20 Unit mass.............50 Display refresh rate ..... 29, 34 Unit mass error ..........80 Stability band width ........ 29, 33 Units ..........14, 15 Stability error..........79 Stabilization time......4, 82, 83, 96 - V - Stable value ...........
