3.2

GS320 System Cabinets

Figure 3–2 shows the front view of the system cabinets. Two system
cabinets house either three system boxes or four system boxes.
hierarchical switch is used to connect the QBBs.
Figure 3–2 GS320 System
System
Box 4
System
Box 3
3-4
AlphaServer GS80/160/320 User's Guide
System
Box 2
System
Box 1
A
PK0615
