2.3.1
Backplane
Each QBB backplane is located at the center of the system box. Figure
2–5 shows an unpopulated backplane (no modules installed) as you
would see it from the front of the system box.
Figure 2–5 Backplane (System Box, Front View)
1
2
3
6
4
2-8
AlphaServer GS80/160/320 User's Guide
4
3
4
5
3
4
3
7
8
9
PK0600
