7.2.2

Show Config Command

Use the show config
configuration. Example 7–3 shows a GS80 system configuration.
Example 7–3 Show Config
P00>>> sh conf
SRM Console X5.7-1838, built on Dec
PALcode OpenVMS PALcode V1.71-2, Tru64 UNIX PALcode V1.64-2
QBB 0 Hard QBB 0
Quad Switch
Duplicate Tag
CPU 0 CPU 0
CPU 1 CPU 1
CPU 2 CPU 2
Memory 0
Memory 1
Memory 2
Memory 3
Directory
IOP
Local Link 0
Remote Link 0
I/O Port 0
PCI Box 0 Riser 0
PCI Bus 0 Hose 0
PCI Bus 1 Hose 1
Local Link 1
Remote Link 1
I/O Port 1
PCI Box 0 Riser 1
PCI Bus 0 Hose 2
PCI Bus 1 Hose 3
Local Link 2
Remote Link 2
I/O Port 2
PCI Box 3 Riser 0
PCI Bus 0 Hose 4
PCI Bus 1 Hose 5
Local Link 3
Remote Link 3
I/O Port 3
PCI Box 3 Riser 1
PCI Bus 0 Hose 6
PCI Bus 1 Hose 7
Global Port
7-8 AlphaServer GS80/160/320 User's Guide
command to display
Compaq Computer Corporation
Compaq AlphaServer GS80 6/631
1 1999 at 02:02:47
QSA rev 2, QSD revs 0/0/0/0
Up To 4 MB Caches
4 MB Cache
4 MB Cache
4 MB Cache
MPA rev 1, MPD revs 1/1
MPA rev 1, MPD revs 1/1
MPA rev 1, MPD revs 1/1
MPA rev 1, MPD revs 1/1
DMA rev 1, DMD rev 0
IOA rev 2, IOD revs 0/0
NE ML rev 2
FE ML rev 2
PCA rev 3
Right Side
64 Bit, 33 MHz
64 Bit, 33 MHz
NE ML rev 2
FE ML rev 2
PCA rev 3
Left Side
64 Bit, 33 MHz
64 Bit, 33 MHz
NE ML rev 2
FE ML rev 2
PCA rev 3
Right Side
64 Bit, 33 MHz
64 Bit, 33 MHz
NE ML rev 2
FE ML rev 2
PCA rev 3
Left Side
64 Bit, 33 MHz
64 Bit, 33 MHz
GPA rev 0, GPD revs 0/0
the entire logical
DTag revs 1/1/1/1
EV67 pass 2.2.2
EV67 pass 2.2.2
EV67 pass 2.2.2
Backplane rev 3
PCI rev 2.1 compliant
PCI rev 2.1 compliant
Backplane rev 3
PCI rev 2.1 compliant
PCI rev 2.1 compliant
Backplane rev 3
PCI rev 2.1 compliant
PCI rev 2.1 compliant
Backplane rev 3
PCI rev 2.1 compliant
PCI rev 2.1 compliant
–
—
˜
˜
™
™
