9) RAM_LED
Do not remove memory modules while DIMM LED is on. It might cause short or other unexpected
damages due to the 2.5V stand by voltage. Remove memory modules only when AC Power cord is
disconnected.
10) PWR_LED
PWR_LED is connect with the system power indicator to indicate whether the system is on/off. It will blink
when the system enters suspend mode. If you use dual color LED, power LED will turn to another color.
GA-7VASFS-FS Motherboard
+
-
Pin No. Definition
1
1
2
3
- 24 -
MPD+
MPD-
MPD-
