Step 1: Install the Central Processing Unit (CPU)

Step1-1: CPU Speed Setup

The system bus frequency can be switched at 100/133/166/200MHz by adjusting system switch
(SW1). (The internal frequency depend on CPU.)
1
SW1
ON
SW1 CPU CLOCK
100MHz
1 ON
O: ON / X :OFF
Default Setting: 100MHz
100MHz : Fix FSB 200MHz CPU
Auto : Support FSB 266/333/400 MHz CPU
Auto
OFF
- 11 -
You must set SW1 to 100MHz when
you used FSB 200MHz CPU.
