Button Function Description
MODE/ENTER
Confirm all exercise data settings or accept, entering choice
RESET
Return to default setting or the beginning
START/STOP
Start or stop the exercise
RECOVERY
Test heart rate recovery status
UP
Changing value up or scrolling through programs
DOWN
Changing value down or scrolling through programs
P1
Program Profile 1
P2
Program Profile 2
P3
Program Profile 3
P4
Program Profile 4
P5
Program Profile 5
P6
Program Profile 6
P7
Program Profile 7
P8
Program Profile 8
P9
Program Profile 9
P10
Program Profile 10
P11
Program Profile 11
P12
Program Profile 12
Display Exercise Data
TIME
Display Range 0:00 – 99:59, Setting Range 0:00 – 99.0
Display Range 0:00 – 99:99, Setting Range 0:00 – 99.9 KM
DISTANCE
CALORIES
Display Range 0:00 – 9999, Setting Range 0:00 - 9990
PULSE
Display Range 30 - 240, Setting Range 30 - 240
Display Range 0 - 99
SPEED
RPM
Display Range 0 - 999
Operation Procedure
1. Connect the power adaptor and the console sound with a long beep. The LCD
momentarily display all segments (figure A) for 2 seconds
2. Computer will display main menu (drawing B)
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013
14
XS1
