Synexis – Synexis RP2 Beltpack Receiver
2.3

Battery status display

• The battery status is displayed
• If only one bar is displayed, you should recharge the receiver as soon as possible.
• If the battery frame is flashing, the batteries are empty and have to be replaced or
recharged.
• If the receiver is equipped with rechargeable NiMH batteries, put it into the
appropriate charger (e.g. Synexis C8 or C10). Despite the Auto-Off function we
recommend turning off the receiver before charging.
The LED indicates the charging status:
LED is flashing blue . . . . . . . . . . The batteries are being charged
LED illuminates blue. . . . . . . . . . The batteries are fully charged
LED is flashing red . . . . . . . . . . . Error
2.4

Headphone connection

• Connect a beyerdynamic headphone with mono or stereo mini jack plug to the
headphone socket .
2.5

How to turn the receiver on/off and control the volume

• Switch on the beltpack receiver by turning the control
• The LED will illuminate:
blue, when a transmitter is turned on and reception available.
red, when there is no transmitter turned on or no reception available.
• Use the control to set the requested volume by turning it more clockwise.
• The selected channel and the battery status are displayed
• After use, switch off the receiver by turning the control
• The LED will go out.
CAUTION
• Do not set the volume too high, because listening at high levels can damage
your hearing.
2.6

How to select and lock a channel

• Use one of the two channel selector buttons
• If you release the channel selector button
stored after approx. 3 seconds.
• If you would like to lock the selected channel to avoid accidental shifting, hold
down the Set button for about 3 seconds. A key symbol will be displayed
The channel is locked.
If you would like to unlock a locked channel, hold down the Set button
about 3 seconds. The key symbol in the display
2.7

How to display the frequency

• Press the Set button briefly.
• The frequency will be displayed
in 4 stages.
clockwise to the right.
.
anti-clockwise.
to select the requested channel.
, the channel will automatically be
will disappear.
for a few seconds.
.
for
8
