OPERATING INSTRUCTIONS
Synexis
Wireless Tour Guide System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Synexis and is the answer not in the manual?

Questions and answers

Related Manuals for Beyerdynamic Synexis

Summary of Contents for Beyerdynamic Synexis

  • Page 1 OPERATING INSTRUCTIONS Synexis Wireless Tour Guide System...

  • Page 2: Table Of Contents

    Synexis C8, C10, C30 chargers........... . . Page Synexis TS2 stationary transmitter, Synexis C8, C10, C20, C30, CHP chargers....Page Synexis TH2 handheld transmitter, Synexis TP2 beltpack transmitter, Synexis RP2 beltpack receiver.
  • Page 3 (2) this device must accept any interference received, including interference that may cause undesired operation. Part 15.21 Statement NOTICE: Changes or modifications made to this equipment not expressly approved by beyerdynamic may void the FCC authorization to operate this equip- ment. Part 15.105 Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 4: Important Safety Instructions

    Synexis – Important Safety Instructions Thank you for selecting the Synexis wireless tour guide system from beyerdynamic. Please take some time to read carefully through this manual before using the system. The Synexis tour guide system provides an optimum digital audio transmission for guided tours e.g. in factories or museums or in multilingual conferences e.g.

  • Page 5: Synexis Ts2 Stationary Transmitter, Synexis C8, C10, C20, C30, Chp Chargers

    • If you connect defective or unsuitable accessories, the equipment could be damaged. Only use connection cables available from or recommended by beyerdynamic. • Do not connect more than six Synexis C8 or C10 chargers in one daisy chain. Switching off - Synexis C8, C10, C30 chargers •...

  • Page 6: Synexis Th2 Handheld Transmitter, Synexis Tp2 Beltpack Transmitter, Synexis Rp2 Beltpack Receiver

    Synexis RP2 beltpack receiver • The Synexis RP2 receiver can produce sound pressures of more than 85 dB (A). 85 dB(A) is the sound pressure corresponding to the maximum permissible volume which is by law (in some countries) allowed to affect your hearing for the duration of a working day. It is used as a basis according to the specifications of industrial medicine.

  • Page 7: Synexis Rp2 Beltpack Receiver

    Insert the supplied NiMH rechargeable batteries according to the polarity marks. Before using the receiver for the first time, the rechargeable batteries inside must be charged e.g. with the Synexis C8 or C10 charger. As an alternative you can use two 1.5 V AA alkaline batteries.

  • Page 8: Battery Status Display

    • If the receiver is equipped with rechargeable NiMH batteries, put it into the appropriate charger (e.g. Synexis C8 or C10). Despite the Auto-Off function we recommend turning off the receiver before charging. The LED indicates the charging status: LED is flashing blue .

  • Page 9: Synexis Th2 Handheld Transmitter

    Synexis TH2 handheld transmitter Controls and indicators Electret condenser microphone head, cardioid polar pattern LED to display mute or charging status (refer also to the chapter “Synexis chargers”) Button with mute function Arrow-shaped buttons for channel selection and frequency display...

  • Page 10: How To Insert/Replace The Batteries

    Insert the supplied NiMH rechargeable batteries according to the polarity marks. Before using the transmitter for the first time, the rechargeable batteries inside must be charged e.g. with the Synexis C8 charger. As an alternative you can use two 1.5 V AA alkaline batteries.

  • Page 11: How To Select A Channel

    Synexis – Synexis TH2 Handheld Transmitter How to select a channel • Press the on/off button and one of the two arrow-shaped buttons simultaneously for approx. 2 seconds until the channel display will flash. • Use the upper or lower arrow-shaped button to select the requested channel.

  • Page 12: Synexis Tp2 Beltpack Transmitter

    Insert the supplied NiMH rechargeable batteries according to the polarity marks. Before using the transmitter for the first time, the rechargeable batteries inside must be charged e.g. with the Synexis C8 or C10 charger. As an alternative you can use two 1.5 V AA alkaline batteries.

  • Page 13: Battery Status Display

    . Make sure the connector will correctly lock in place. Note • In order to avoid popping noise in the Synexis RP2 receiver, you should connect the microphone when Synexis TP2 receiver is turned off. How to turn the transmitter on/off •...

  • Page 14: How To Select And Lock A Channel

    Synexis – Synexis TP2 Beltpack Transmitter How to select and lock a channel • Use one of the two channel selector buttons to select the requested channel. • If you release the channel selector button , the channel will automatically be stored after approx.

  • Page 15: Synexis Ts2 Stationary Transmitter

    Synexis – Synexis TS2 Stationary Transmitter Synexis TS2 stationary transmitter Controls and indicators On/off switch Level control microphone input Level control AUX input OLED display to indicate channel, AF level, frequency and channel lock function (on delivery with protective foil)

  • Page 16: How To Select And Lock A Channel

    Synexis – Synexis TS2 Stationary Transmitter How to select and lock a channel • Select a channel with the channel selector buttons • Press the up or down button until the requested channel is displayed • Release the button to store the selected channel.

  • Page 17: Synexis C8 / C10 / C20 / C30 / Chp Chargers

    Synexis – Synexis C8 / C10 / C20 / C30 / CHP Chargers Synexis C8 / C10 / C 20 / CHP chargers Controls and indicators Synexis C8 Charging status of handheld transmitter Charging compartment for handheld transmitter Power on LED...
  • Page 18 Synexis – Synexis C8 / C10 / C20 / C30 / CHP Chargers Synexis C10 Power on LED Charging compartments for beltpack transmitters / beltpack receivers Ground Fuse Mains connection Connection to loop through another charger...
  • Page 19 Synexis – Synexis C8 / C10 / C20 / C30 / CHP Chargers Synexis C20 DC connection for power adapter Power on switch with LED Charging compartment for handheld transmitter Charging compartments for beltpack transmitters / beltpack receivers Synexis C30...
  • Page 20 Synexis – Synexis C8 / C10 / C20 / C30 / CHP Chargers Synexis CHP DC connection for power adapter Charging compartments for beltpack transmitters / beltpack receivers / handheld transmitters Caution The beltpack transmitter/receiver and handheld transmitter cannot simultaneously be inserted into the same charging compartment!

  • Page 21: How To Use The Charger

    • The Synexis C8 or C10 charger has been designed for the installation into a 19" rack (3 U). When you install the charger into a 19" rack, make sure that the charger is connected to a switchable mains supply.
  • Page 22 Synexis – Synexis C8 / C10 / C20 / C30 / CHP Chargers Synexis C20 • Put the case horizontally down and open the cover all the way to the stop. • Connect the power adapter to the Synexis C20 charger and to AC power.

  • Page 23: Charging

    When the Synexis handheld transmitter is equipped with rechargeable batteries, you can recharge it in the appropriate charging compart- ment of the Synexis C8, C20 (display and mute button point upwards) or CHP charger (refer to the appropriate drawing). For the Synexis C30 charging case there is an optional compartment available to charge the handheld transmitter.

  • Page 24: General Instructions For A Trouble-Free Operation

    Furthermore, the group should be kept within optical vision for safety reasons. • To avoid popping try holding the Synexis TH2 microphone at a slight angle below the mouth. • Blowing into the microphone to check that it is working can cause serious damage. Speaking a few words or counting is recommended.

  • Page 25: Components

    Synexis CTH 30 Charging compartment for handheld transmitter ....... . .

  • Page 26: Frequencies

    Synexis – Frequencies Frequencies Channel display Frequency 216.025 MHz* 216.075 MHz* 216.125 MHz 216.175 MHz 216.225 MHz 216.275 MHz 216.325 MHz 216.375 MHz 216.425 MHz* 216.525 MHz* 216.575 MHz* 216.625 MHz 216.675 MHz* 216.725 MHz 216.775 MHz 216.825 MHz 216.875 MHz* 216.925 MHz*...

  • Page 27: Technical Specifications

    Synexis – Technical Specifications Technical specifications Synexis RP2 beltpack receiver Oscillation type ......PLL synthesized control OSC Carrier frequency range.
  • Page 28 Weight ....... . 1257.5 g [2.7 lbs] *In order to change the transmitter internally to “Aux”, please contact the Service department at beyerdynamic. **In order to change the RF output power internally, please contact the Service department at beyerdynamic. Please note country-specific regulations.
  • Page 29 Synexis – Technical Specifications Synexis CHP charger Power adapter input ..... . AC 100 - 240 V / 47 - 63 Hz Power adapter output .
  • Page 30 Theresienstr. 8 | 74072 Heilbronn – Germany Tel. +49 (0) 7131 / 617 - 0 | Fax +49 (0) 7131 / 617 - 204 info@beyerdynamic.de | www.beyerdynamic.com Weitere Vertriebspartner weltweit finden Sie unter www.beyerdynamic.com For further distributors worldwide, please go to www.beyerdynamic.com...
