Quick Start Guide – Synexis
Synexis TP Beltpack Transmitter
On/off switch
LED to display operating or charging status (refer to the Synexis charger manuals)
Push-button to mute the microphone
Microphone connection, 4-pin mini XLR
Set button
Line-In input to connect an audio source such as MP3 player, mini stereo jack (3.5 mm)
Belt clip
Lid of the battery compartment
Charging contacts on the right and left hand side
Channel selector buttons
OLED display
Mounting for strap
Gain switch, 3 stages Hi/Mid/Low
Battery compartment
Antenna
Operating instructions for Synexis TP beltpack transmitter
1. Connect a microphone to the 4-pin mini XLR socket
connector will correctly lock in place.
Note
In order to avoid popping noise in the Synexis RP receiver, you should
connect the microphone when Synexis receiver is turned off.
2. Turn on the beltpack transmitter with the on/off switch
illuminate blue. The selected channel and the battery status are displayed
Make sure that transmitter and receiver operate on the same channel.
3. If you wish to select a different channel, Use one of the two channel selector
buttons to select the requested channel. If you release the channel selector
button , the channel will automatically be stored after approx. 3 seconds.
If you would like to lock the selected channel to avoid accidental shifting,
hold down the Set button
displayed . The channel is locked.
If you would like to unlock a locked channel, hold down the Set button
about 3 seconds. The key symbol in the display
4. If you would like to mute the connected microphone, press the mute button
The LED will flash red. "Mute" is displayed
function, press the mute button
5. You can connect an audio source (e.g. MP3 player) to the Line In input
you want to play recordings during guided tours.
6. After use turn off the beltpack transmitter with the on/off switch
LED will go out.
7. If the battery status displays only one bar
mitter or replace the alkaline batteries as soon as possible. If the transmitter
is equipped with rechargeable NiMH batteries, turn it off and put it into the
appropriate charger (e.g. Synexis C8 or C10). The LED
status:
LED is flashing blue . . . . . . . . . . . . . . The batteries are being charged
LED illuminates blue . . . . . . . . . . . . . The batteries are fully charged
LED is flashing red . . . . . . . . . . . . . . . Error
. Make sure the
. The LED
for about 3 seconds. A key symbol will be
will disappear.
. In order to turn off the mute
once again.
, you should recharge the trans-
indicates the charging
Synexis TH Handheld Transmitter
Electret condenser microphone head, cardioid polar pattern
LED to display mute or charging status (refer to the Synexis charger manuals)
Button with mute function
Arrow-shaped buttons for channel selection and frequency display
OLED display
On/off and Set button
Battery compartment
Gain switch Hi/Low
Lid of the battery compartment
Charging contacts on the right and left hand side
Operating instructions for Synexis TH handheld transmitter
1. Turn on the handheld transmitter by pressing the on/off button
3 seconds.
2. If you wish to select a different channel, press the on/off button
of the two arrow-shaped buttons
until the channel display
will
button to select the requested channel. The channel will automatically be
.
stored after approx. 2 seconds. If you press briefly the on/off button
channel will immediately be stored.
3. There are three different mute functions available:
Push-To-Mute (PTM): Hold down the mute button
Push-To-Talk (PTT):
Mute Toggle (MTG): Press the button
for
To select a different mute function, press the on/off button
.
button simultaneously for approx. 2 seconds until the channel and mute
display will start to flash. Use the mute button
mute function. After approx. 2 seconds the selected mute function will auto-
, if
matically be stored.
If the LED
. The
will flash red, the microphone is muted.
4. After use turn off the handheld transmitter by pressing the on/off button
for approx. 3 seconds.
5. If the battery status displays only one bar
mitter or replace the alkaline batteries as soon as possible. If the transmitter
is equipped with rechargeable NiMH batteries, turn it off and put it into the
appropriate charger (e.g. Synexis C8). The LED
status:
LED is flashing blue . . . . . . . . . . . . . . The batteries are being charged
LED illuminates blue . . . . . . . . . . . . . The batteries are fully charged
LED is flashing red . . . . . . . . . . . . . . . Error
simultaneously for approx. 2 seconds
will flash. Use the upper or lower arrow-shaped
phone.
Hold down the mute button
phone.
briefly to switch between muted
and activated microphone.
will illuminate blue, the microphone is activated. If the LED
, you should recharge the trans-
for approx.
and one
, the
to mute the micro-
to activate the micro-
and the mute
to select the requested
indicates the charging
