Synexis – Synexis TP2 Beltpack Transmitter
4.3

Battery status display

• The battery status is displayed
• If only one bar is displayed, you should recharge the receiver as soon as possible.
• If the battery frame is flashing, the batteries are empty and have to be replaced or
recharged.
• If the transmitter is equipped with rechargeable NiMH batteries, put it into the
appropriate charger (e.g. Synexis C8 or C10). Despite the Auto-Off function we
recommend turning off the transmitter before charging.
The LED indicates the charging status:
LED is flashing blue . . . . . . . . . . The batteries are being charged
LED illuminates blue. . . . . . . . . . The batteries are fully charged
LED is flashing red . . . . . . . . . . . Error
4.4

How to set the gain

• With the 3-stage (Hi/Mid/Low) gain switch
distant miking. Remove the lid of the battery compartment
switch.
Position "Low" = set switch to "L"
Position "Mid" = set switch to "M"
Position "High" = set switch to "H"
4.5

Microphone connection

• Connect a microphone to the 4-pin mini XLR socket
will correctly lock in place.
Note
• In order to avoid popping noise in the Synexis RP2 receiver, you should connect
the microphone when Synexis TP2 receiver is turned off.
4.6

How to turn the transmitter on/off

• Turn on the beltpack transmitter with the on/off switch
• The LED will illuminate blue.
• The selected channel and the battery status are displayed
• After use turn off the beltpack transmitter with the on/off switch
• The LED will go out.
in 4 stages.
you can set the gain for close or
to access the
. Make sure the connector
.
.
.
13
L M H
