Synexis – Synexis RP2 Beltpack Receiver
2.

Synexis RP2 beltpack receiver

2.1

Controls and indicators

Headphone socket, mini jack (3.5 mm)
LED to display operation or charging status
(refer also to the chapter "Synexis chargers")
On/off and volume control
Set button
Charging contacts
Lid of the battery compartment
Belt clip
Channel selector buttons
OLED display to indicate the channel, battery status, frequency and
channel lock function (on delivery with protective foil)
Mounting for strap
Battery compartment
2.2

How to insert/replace the batteries

• Remove the belt clip by levering out the clip with pressure to the rear from the
lock-in position (see arrow in chapter "Controls and indicators"). Slide down the
lid to open the battery compartment
• Insert the supplied NiMH rechargeable batteries according to the polarity marks.
Before using the receiver for the first time, the rechargeable batteries inside
must be charged e.g. with the Synexis C8 or C10 charger. As an alternative you
can use two 1.5 V AA alkaline batteries.
• If you wish to wear the receiver with a strap around your neck, you can mount
a strap to the right and left hand side.
• Close the battery compartment
.
by sliding the lid to the top.
