4. Operation
Using the Main Menu
Please note:
•
•
To adjust the IP address:
1.
2.
3.
4.
5.
pìÄåÉí
From the System Menu, select
SUBNET
Figure 4-8. MatrixPRO Subnet Menu
When this menu item is selected (and DHCP is off), the cursor (
right-most digit in the address.
Please note:
•
•
To adjust the Subnet Mask:
1.
2.
3.
4.
5.
38
The default IP address is 192.168.000.243.
If DHCP is on, the IP address appears between brackets, and cannot be adjusted.
Ensure that DHCP is off.
On the IP Address Menu, rotate the knob to change the value of the digit to which
the cursor is pointing.
Press SEL to update the number and advance the cursor one place to the left.
Repeat steps 1 and 2 as required. Note that repeatedly pressing SEL advances
through the digits, skipping the decimal-point field delimiter.
To accept the new IP address, press ESC at any time to exit the menu. The new
IP address will take effect at this point.
Subnet Mask
255.255 .255. 000
The default Subnet Mask is 255.255.255.000.
If DHCP is on, the Subnet Mask appears between brackets, and cannot be
adjusted.
Ensure that DHCP is off.
On the Subnet Menu, rotate the knob to change the value of the digit to which the
cursor is pointing.
Press SEL to update the number and advance the cursor one place to the left.
Repeat steps 1 and 2 as required. Note that repeatedly pressing SEL advances
through the digits, skipping the decimal-point field delimiter.
To accept the new Subnet Mask, press ESC at any time to exit the menu. The
new Subnet Mask will take effect at this point.
to display the Subnet Menu.
^
^
MatrixPRO • 8x8 DVI Router • User's Guide
) is positioned under the
