- Page 1 AW130BD2 Belt & Disc Sander A X M I N S T E R W H I T E Axminster Reference No: AW130BD2 www.axminster.co.uk...
-
Page 2: Table Of Contents
Index of Contents... Page No. Index of Contents.......................... 01 Declaration of Conformity......................01 What’s in the Box........................02-03 General Instructions for 230V Machines................04 Specific to Sanding Machines.................... 05-06 Specification........................... 06 Assembly..........................07-08-09 Setting Up........................09-10-11-12 Illustration and Parts Description..................13-14 Sanding Configurations...................... -
Page 3: What's In The Box
What’s in the Box... A X M I N S T E R W H I T E Model Number: 1 off: AW130BD2 Belt and Disc Sander (Sanding Disc & Belt Assembled) 1 off: Dust Extraction Moulding 1 off: Sanding Disc Cast Iron Table... - Page 4 Keep this Instruction Manual readily accessible for any others who may also be required to use the machine. www.axminster.co.uk...
-
Page 5: General Instructions For 230V Machines
General Instructions for 230V Machines... A X M I N S T E R W H I T E Good Working Practices/Safety The following suggestions will enable you to observe good working practices, keep yourself and fellow workers safe and maintain your tools and equipment in good working order. -
Page 6: Specific To Sanding Machines
Specific to Sanding Machines... A X M I N S T E R W H I T E Warning! The sanding disc cannot be declutched from the belt and vice versa, both functions are active when the machine is running. Remember this, and do not leave loose objects of any description on the machine if it is going to be used. -
Page 7: Specification
Above all, OBSERVE…. make sure you know what is happening around you, and USE YOUR COMMON SENSE. Specification... Axminster No. 200059 Model: AW130BD2... -
Page 8: Assembly
NOTE: When tilting the table, it should be adjusted so that the gap between the belt and the table is no larger than 1.5mm (1/16"). A gap greater than this could cause small workpieces to slip down between the belt and table. www.axminster.co.uk... - Page 9 Assembly... A X M I N S T E R W H I T E Dust Extraction Moulding Fig 5 Fig 6 Remove the four Phillips screws (K) Dust extraction moulding (B) assembled and place safely aside Using a Phillips screwdriver remove the four M4 x 10mm pan head Phillips screws and washers (K), place safely aside (See fig 5).
-
Page 10: Setting Up
Assembly... A X M I N S T E R W H I T E Mitre Fence Fig 12 Fig 13 ‘T’ slot Slide the mitre fence (E) into the table ‘T’ slot Locate the mitre fence (E) and slot it into the table (C) ‘T’ slot (See figs 12-13). Setting Up... - Page 11 Setting Up... A X M I N S T E R W H I T E Scale Pointer Fig 16 Fig 17 Pointer Fig 18 Fig 19 Adjust the table (D) until it is 90˚ Square perpendicular to sanding belt perpendicular to the belt Place the square on the table (D), up against the belt;...
- Page 12 Setting Up... A X M I N S T E R W H I T E Tracking the Belt To check the sanding belt is tracking properly you first have to remove the side cover, follow the instruction below: First undo the two Phillips screws (a) and (b) as shown in figs 22-23 and place the screws safely aside. Undo and remove the clamping knob (c) below the guard, remove the belt access cover (d) and place safely aside (See figs 24-25).
- Page 13 Setting Up... A X M I N S T E R W H I T E Adjusting the Platen The Platen (f) should be adjusted so that it almost touches the back of the abrasive belt. If it requires adjustment loosen the two caphead screws (g) that secure it to the frame and adjust until correct. Re-tighten the screws (See figs 27-28).
-
Page 14: Illustration And Parts Description
ON/OFF Control box Abrasive disc Scale Pointer Pointer rest screw A) AW130BD2 Belt and Disc Sander E) Mitre Fence B) Dust Extraction Moulding F) Rubber Feet C) Sanding Disc Cast Iron Table G) M8 x 20mm Large Lift & Shift Handle D) Sanding Belt Cast Iron Table H) M6 x 15mm Small Lift &... -
Page 15: Illustration And Parts Description
Illustration and Parts Description... A X M I N S T E R W H I T E Belt access cover Disc guard Clamping knob Platen Dust extraction outlet Dust extraction outlet Chassis On/Off Control box Grub screw for leveling the table... -
Page 16: Sanding Configurations
Sanding Configurations... A X M I N S T E R W H I T E Disc Sanding Belt Sanding Angle Sanding... -
Page 17: Changing The Abrasive Belt/Disc
Changing the Abrasive Belt/Disc... A X M I N S T E R W H I T E Sanding Belt DISCONNECT THE SANDER FROM THE MAINS SUPPLY Remove the belt access cover as Fig 32 Fig 31 described on page 11 Tracking the Belt, and place safely aside. -
Page 18: Maintenance
2. Defective or damaged the sander switch cord 3. Defective or damaged switch relay 4. Burned out motor 4. Contact Axminster Tool 5. Blown fuse Centre on 0800 371822 and asked to be transferred to the “Technical Sales” Department Machine slows down while 1. -
Page 19: Wiring Diagram
Wiring Diagram... A X M I N S T E R W H I T E FREEPHONE 0800 371822... -
Page 20: Parts Breakdown
Parts Breakdown... A X M I N S T E R W H I T E... - Page 21 A X M I N S T E R W H I T E...
-
Page 22: Parts List
Parts List... A X M I N S T E R W H I T E www.axminster.co.uk... -
Page 23: Notes
Notes... A X M I N S T E R W H I T E FREEPHONE 0800 371822... - Page 24 Axminster Reference No: AW130BD2 A X M I N S T E R W H I T E...
