3 – Connections : Slot card configuration
Slot card configuration
As mentioned, you can expand the capabilities of the
DM-4800 with the optional slot cards available.
These cards are as follows:

IF-AN/DM

providing eight channels each of A/D
and D/A conversion. Referred to on screen as
Card . Can be installed in any of the four slots.
Figure 3.4: IF-AN/DM (at left) and IF-AE/DM (at
right)
The parameters available allow the viewing (but not
the setting) of the word length (for input and output)
and the eight output tracks associated with the card.

IF-AE/DM

providing eight channels of input and
output in AES/EBU format. Referred to on screen as
. Can be installed in any of the four slots.
AES3 Card
The inputs and outputs can be set independently for
normal operation or double-speed operation.
An on-screen DETAIL button allows the viewing of
information related to each of the four stereo input
and output channels (a popup appears on screen).
MUTE DEFEAT can be enabled or disabled for each of
the four channels (see above for details of this).
management facilities, master SPL settings, etc.
52
TASCAM DM-4800 User's Manual
The current status of the input and output channels is
also shown on the screen.
AD/DA
Figure 3.5: IF-TD/DM (at left) and IF-AD/DM (at

IF-TD/DM

in TDIF-1 format. Referred to on screen as
. Can be installed any of the four slots.
Card

IF AD/DM

in ADAT "lightpipe". Referred to on screen as
Card . Can be installed in any of the four slots.
Figure 3.6: IF-FW/DM (at left) and IF-SM/DM (at

IF-FW/DM

each direction over an IEEE.1394 interface (as well
as carrying MIDI to and from a host computer).
Referred to on screen as
slot 1 or slot 3.

IF-SW/DM

monitoring setups, including downmixing and bass
Referred to on screen as
right)
providing eight channels of digital I/O
providing eight channels of digital I/O
right)
Provides 24 channels of audio I/O in
FW Card . Can be installed in
Provides facilities for analog surround
SRND MONITOR Card
TDIF-1
ADAT
.
