Perform with the following steps to install the drivers for Windows 95/98. When you first turn on your computer after installing the CyberSerial PCI card, Windows will notify you of “New Hardware Found”. From the choices listed on the screen, select: “•...
Page 2
The port is ready to connect your new device. Speed Change The default baud rate for your CyberSerial PCI is 115.2Kbps. If you connect a higher speed device, you may change the baud rate to support up to 460Kbps. Two DOS utility files, cs1000hi.exe and cs1000lo.exe, are provided for changing...
Page 3
Installation diskette. Perform the following steps to install the Windows NT 4.0 drivers. 1 Start Microsoft Windows NT Version 4.0. 2. Insert the CyberSerial PCI Driver Installation diskette in the floppy drive A. 3. From the desktop, click on My Computer, then double- click on 3 1/2 Floppy (A:) and NT subdirectory.
Page 4
CyberSerial PCI screen to change it to a compatible setting. Speed Change The default baud rate for your CyberSerial PCI is 115.2Kbps. If you connect a higher speed device, you may change the baud rate to support up to 460Kbps. The DOS cs1000hi.exe utility is provided for this purpose.
Page 5
For DOS support, run the dosinst.bat file to copy DOS driver files cs1000hi.exe, cs1000lo.exe and cs1000pc.exe to subdirectory c:\siig\cs1000> on drive C. 1. Insert the CyberSerial PCI Driver Installation diskette in the floppy drive. 2. From the C:\> prompt, type and press <Enter>...
Page 6
For example: device=c:\siig\cs1000\cs1000pc 3-3.2 Speed Changer - cs1000hi.exe/cs1000lo.exe The default baud rate for your CyberSerial PCI is 115.2Kbps. If you connect a higher speed device, you may change the baud rate to support up to 460Kbps. Two DOS utility files, cs1000hi.exe and cs1000lo.exe, are provided for changing...
Page 7
3-3.3 IRQ Setup in Windows 3.x If you are using Windows 3.x, proceed with the following steps to set the IRQ for the CyberSerial PCI in Windows 3.x: 1. Determine the CyberSerial PCI’s IRQ setting: Run the cs1000pc.exe utility by typing the following...
Page 8
CyberSerial PCI User's Manual 2. Set the IRQ for the CyberSerial PCI in Windows 3.x: a. From the Main Menu, double-click on the Control Panel, then Ports. b. Double-click on the new serial port. Then click on Settings, then Advanced.
