3.3.2 Install Hard disk

After taking out Cooler, let's focus on Installing Drives Cage. Slide hard disk into the Drives Cage,
and use screw no. 3 to screw it firmly to the cage.
Heat dissipation side faces up.

3.3.3 Install Floppy Drive

Slide in the floppy drive as shown. Use screw no.2 to screw the 3
Front Mark
Front mark
11
The bottom of Cooler had been protected
with a plastic cover when shipped.
Please take it off when you want to put the
cooler on CPU.
rd
Front mark
th
and 6 hole separately.
