3.3.4 Install Optical Drive

Slide in the optical drive. Use screw no.2 to screw the optical drive firmly.

3.4 Cables and Connectors

1. Before connecting necessary cables and connector to motherboard, you may found most of the
I/O panel connectors (IEEE1394, USB, Front Audio and S/PDIF) both at front panel and back
panel on motherboard have had been connected properly as shown.
Optical device must aim
at the edge of Drives
Generally there are special screws for
hard disk in the parcel when you buy a
new hard disk. There will be no harm
done using those screws. If no screws
are attached, use those packed in the
accessory parcel. Make sure to use the
NO.2 screws. (See page 7)
I/O connectors have
had been inserted
previously.
12
Don't mess up screws!!
