3.3.2 Install Hard disk

After taking out Cooler, let's focus on Installing Drives Cage. Slide hard disk into the Drives Cage,
and use screw no. 3 to screw it firmly to the cage.
Heat dissipation side face up.

3.3.3 Install Floppy Drive

1. Slide in the floppy drive as shown. Use screw no.2 to screw the 3
Front Mark

3.3.4 Install DVD-RW Drive

1. Slide in the DVD-RW drive. Use screw no.2 to screw the DVD-RW firmly.
Front mark
14
Front mark
rd th
and 6 hole separately.
DVD-RW must aim at the
edge of Drives Cage.
