3.5.4 Install CPU On Socket A
1.
Erect CPU socket lever up and gently put CPU onto Socket
Lever
2.
Press lever back to CPU socket, and then it's done.
3.5.5 Install CPU On Socket 479
1.
Remove plastic membrane from CPU socket and make sure the drop-shaped indicator on socket
screw aims at open direction (the default is open).
Plastic membrane
Socket screw
Drop-shaped indicator
17
