UTP Reference
UTP Hub-to-MAU
Wiring

Figure 47: RJ45

Figure 48: Hub-to-MAU
Wiring (A) Usable
and (B) Unusable
48
Figure 47 shows a UTP cable with an RJ45 connector. For a 10BASE-T link
between a hub and a Medium Attachment Unit (MAU) or Network Interface
Controller (NIC), the cable is wired straight-through. That is, an RJ45
receptacle at the hub would wire pin-to-pin to the RJ45 receptacle at the
MAU, as shown in Figure 48.
1
RJ45 Pin
1
TD+
2
TD-
3
RD+
4
Not Used
5
Not Used
6
RD-
7
Not Used
8
Not Used
This cable will not work for 10BASE-T.
Note that 3 and 6 are twisted, but are not a pair.
RJ45 Pin
1
TD+
2
TD-
3
RD+
4
Not Used
5
Not Used
6
RD-
7
Not Used
8
Not Used
Pin 1
A
Pair twisted as per Level 3, 4 or 5 cable.
1
1
B
RJ45 Pin
1
TD+
2
TD-
3
RD+
4
Not Used
5
Not Used
6
RD-
7
Not Used
8
Not Used
RJ45 Pin
1
TD+
2
TD-
3
RD+
4
Not Used
5
Not Used
6
RD-
7
Not Used
8
Not Used
