Hardware Installation
Figure 8: Network Appliqués
12
In addition to the AUI interface, optional appliqués are available for
connection with fiber optic (ST, SC, or SM), thinnet (BNC) or UTP (RJ45)
cabling. Figure 8 shows the available (appliqué faceplates.
AT-A1 (SMA)
AT-A3 (ST)
AT-A8 (BNC)
During the swap-out of an
you will be removing screws and inserting metal parts into the appliqué opening
You can combine any hub model with any of the six network port
appliqués shown in Table 2.
Table 2: ATl Network Port Appliqués
Suffix
-x 1
-x 2
-x 3
-x 5
-x 8
-x 9
AT-A2 (SC)
AT-A5 (AUI)
AT-A9 (10BASE-T)
Note
, i
appliqué t is advisable to turn off the power since
Network Interconnect Appliqué
SM/SMA Fiber Optic Port
SC Fiber Optic Port
ST Fiber Optic Port
AUI Port
BNC Port
RJ45 Port
.
