Chapter 8

AT-3624T Connectivity

AT-3624T Modules

Figure 41: AT-3624T Front and
Back Panels
The AT-3624T has 24 10BASE-T ports incorporated in two Telco 50-pin
(RJ21) receptacles for UTP. Figure 41 shows the AT-3624T faceplate. A
pin-out table and information on attachment accessories is available in
Appendix B.
Telco (RJ21) ports
Front
Back
A U I
Port
p o r t
activity
LEDs
Interrepeater
Firmware
bus port
cassette
port
R S 2 3 2
p o r t
Hub
status
LEDs
41
