Electrical Safety and Installation
Requirements
RADIATED ENERGY
U.S. Federal Communications
Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and , if not installed and used in
accordance with this instruction manual, may cause harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his
own expense.
Note: Modifications or changes not expressly approved of by the manufacturer or the FCC, can void your right to operate this
equipment.
Canadian Department of Communications
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
STANDARDS: This product meets the following standards
RFI EmissionEN55022 Class A
WARNING: In a domestic environment this product may cause radio interference in which case the user may be required to take
adequate measures.
Immunity EN50082-1
Electrical Safety EN60950, UL1950, CSA 950
SAFETY
LIGHTNING DANGER
DANGER: DO NOT WORK on equipment or CABLES during periods of LIGHTNING ACTIVITY.
This is a "CLASS 1 LED PRODUCT"
OPERATING TEMPERATURE: This product is designed for a maximum ambient temperature of 40 degrees C.
ENVIRONMENTAL AIR NOTICE
Caution: UL listed for use in other Environmental Air Spaces in Accordance with Article 300-22(C) of the U.S.A National Electrical
Code.
Note: Product is not Plenum rated
ALL COUNTRIES: Install product in accordance with local and National Electrical Codes.
NORMEN : Dieses Produkt erfüllt die Anforderungen der nachfolgenden Normen.
Hochfrequenzstörung EN55022 Klasse A
WARNUNG : Bei Verwendung zu Hause kann dieses Produkt Funkstörungen hervorrufen. In diesem Fall müßte der Anwender
angemessene Gegenmaßnahmen ergreifen.
Störsicherheit EN50082-1
Elektrische Sicherheit EN60950, UL1950, CSA 950
SICHERHEIT
GEFAHR DURCH BLITZSCHLAG
GEFAHR : Keine Arbeiten am Gerät oder an den Kabeln während eines Gewitters ausführen
Das ist ein "LED Produkt der Klasse 1"
BETRIEBSTEMPERATUR
Dieses Produkt wurde für den Betrieb in einer Umgebungstemperatur von nicht mehr als 40 C entworfen.
ALLE LÄNDER: Installation muß örtlichen und nationalen elektrischen Vorschriften entsprechen.
