Connectivity

Wiring Configuration
Rules

Chassis Configuration

Table 1 shows the various models of manageable AT-3600 Series hubs. You
can mix any combination of model types in a department concentrator
chassis for maximum flexibility. Subsequent chapters of this manual
describe the individual model types in detail, including faceplate design,
connection type and LED displays.

Table 1: Manageable AT-3600 Series Hub Models

Model Number Port Count
AT-3606F or
AT-3606F/ST
AT-3606F/SMA or
AT-3606F/SM
AT-3606F/SC
AT-3608
AT-3612T 12
AT-3612TR 12
AT-3624T 24
AT-3624TR 24
References in this manual to SMA and SM are interchangeable, both being
acronyms for Sub Miniature Assembly.
Depending on the medium you choose, there are certain wiring practices
you should follow to ensure the reliability of communication throughout
the network. The AT-3600 Series complies with IEEE standards for 802.3
Carrier Sense Multiple Access with Collision Detection (CSMA/CD)
Ethernet. You should refer to these standards when implementing your
network. Some important guidelines for ensuring integrity in network
wiring appear in later chapters of this manual, as appropriate for the
medium type.
You can use a single manageable AT-3600 Series hub in standalone mode
or as part of a department concentrator housed in a chassis. Various
chassis models are available for desktop or rackmount configurations.
These include 1-, 2-, 3-, 4-, 7-, and 8-module combinations for desktop or
19-inch rackmount installations with either standard or segmented
backplanes. Call your ATI sales representative for details.
Media/Connector Type
6 Fiber Optic (10BASE-FL)
with Straight Tip (ST) Connectors
6 Fiber Optic (10BASE-FL)
with Sub Miniature Assembly (SMA) Connectors
6 Fiber Optic (10BASE-FL)
with Subscriber Channel(SC) Connectors
8 Thinnet (10BASE2)
with Bayonet Nut Couple (BNC) Connectors
with Telco 50-pin (RJ21) Connector
with RJ45 Connectors
with 2 Telco 50-pin (RJ21) Connectors
with RJ45 Connectors
Note
CentreCOM 3600 Series Hub/Repeaters
UTP (10BASE-T)
UTP (10BASE-T)
UTP (10BASE-T)
UTP (10BASE-T)
3
