Replacing The Fuser Cleaning Roller - NEC SuperScript 4200N Online User's Manual

R
EPLACING THE
R
OLLER
Part Number 20-211
1. Turn off the printer and allow it to cool (A).
2. Open the Top Cover (B).
3. Open the Lock Tabs (C).
4. Remove the used Fuser Cleaning Roller (D).
5. Install the replacement Fuser Cleaning Roller (E).
6. Close the Lock Tabs and the Top Cover of the printer (F).
A B
E
F C
USER LEANING
C
F
7. Reset the Operator Panel to make sure the consumables
usage information is current (G). Follow these steps.
a. Press Online .
OFFLINE
b. Press Menu .
CONTROL
c. Press Next until
USAGE STATUS
display, and then press Select .
d. Press Next until
ROLLER REPLACE?
display, and then press Select .
e. When the panel displays
again.
D
G

Replacing the Fuser Cleaning Roller

appears on the display.
appears on the display.
appears on the
appears on the
, press Select
CONFIRM
Power Warning Online
Menu OnLine
Data OHT Label
Feed Item Media
Select
Previous Next
79
