APPENDIX A
PRINTER SPECIFICATIONS
O S
PERATING PECIFICATIONS
Print speed
Letter: 12 sheets/minute
Print method
Electrophotographic
Warming-up Time
30 seconds (at ambient temperature of 23°C/115VAC)
First Printout Time
15 seconds
note:
The printing speed listed above is the value when
the paper is fed from the standard 270-sheet Cassette.
The time is measured from when the print signal is
received at standby state to the time when the paper is
ejected.
Recommended Duty Cycle
15,000 pages per month maximum
Processor
66MHz PowerPC RISC
Random Access Memory (RAM)
4 MB
Resolution
1200 dpi Class
Printer Language Emulations
SuperScript 1400 Series Printer Driver
Automatic Jam Recovery
Automatically reprints jammed pages when enabled
Interface Ports
• IEEE 1284-compliant parallel
• USB
Power Requirements
100 - 127VAC, 50/60Hz ± 3Hz
Power Consumption
Operating average: 300 watts (W) average during
operation
In Power-save mode: Less than 12 watts (W)
Temperature
Operating: 50°F to 86°F (10°C to 30°C)
Non-operating in packed condition:
-4°F to -104°F (-20°C to 40°C)
Humidity
Operating: 2 0-80% RH (non-condensing)
Non-operating: 10-90% RH (non-condensing)
Dimensions (without options)
Width: 15.1" (383.4 mm)
Depth: 17.8" (453.3 mm)
Height: 10.2" (260.0 mm)
Weight
With Toner Cartridge (no packing): 21.3 lb (9.7 kg)
Toner Cartridge: about 3.1 lb /1.4 kg
550-sheet 2nd Cassette: 12.6 lb (5.7 kg)
Administrative Compliance
• UL 1950D3
• CSA C22.2 950D3
• FCC part 15, subpart B, Class B
• Laser Safety CDRH Class 1
• ENERGY STAR Compliant
