4. Locate and install the boot drives (those with the completed labels).
Install the RAID boot drives into slots 1, 2, and 3 of the disk section, as shown in
the following figure.
x GB
ADP
x GB
ADP
x GB
ADP
Install the non-RAID boot drive into slot 1 of the disk section, as shown in the
following figure.
x GB
ADP
5. Install the remaining disk drives into the slots. Fill each slot upward as you install the
drives. There should be no empty slots between the drives.
0
0
2
CH
ID
0
0
1
CH
ID
0
0
0
CH
ID
0
0
0
CH
ID
Slot 8
Slot 7
Slot 6
Slot 5
Slot 4
Slot 3
Slot 2
Slot 1
Slot 8
Slot 7
Slot 6
Slot 5
Slot 4
Slot 3
Slot 2
Slot 1
