4
DDC2B Display Data Channel standard
Head-mounted displays and shutter glasses (frame sequential and interlaced stereo required)
Onboard texture memory with full mipmapped trilinear interpolated texture processing
Digital Video Interface (DVI)-I digital flat panel display support
External Connectors
The Intense3D Wildcat 4110 video card has three standard external connectors (see Figure 1):
3-Pin, MiniDIN stereo sync output connector
15-Pin, D-sub analog video output connector
DVI-I output connector
Figure 1. Wildcat 4110 External Connectors
See Appendix B, "Connectors," for detailed information on each of the Intense3D Wildcat 4110
connectors.
