Imc Networks Technical Support; Specifications - IMC Networks IE-MiniMc Operation Manual

IMC Networks Technical Support

Tel: (949) 465-3000 or (800) 624-1070 (in the U.S. and Canada);
+32-16-550880 (Europe)
Fax: (949) 465-3020
E-Mail: techsupport@imcnetworks.com
Web: www.imcnetworks.com

Specifications

Ethernet Connections
10/100 BaseT, Auto Negotiation, Auto-Cross, Flow Control, 1916 MTU, Broadcast
Storm Protection, Full Line-Rate Forwarding.
Input Specifications
DC terminal 7 to 50 VDC, 1 to 0.1A
DC jack 5 VDC
PoE When IE-MiniMc uses PoE technology to be a PD, the maximum
supply voltage is 50V
AC Wall Adapter
100 to 240 ±10% VAC input, 5 VDC output, 2A max.
Operating Temperature
-13°F to +185°F (-25°C to +85°C) DC configuration
+14°F to +122°F (-10°C to +50°C) with AC wall adapter
Storage Temperature
-40°F to 185°F (-40°C to 85°C)
Humidity
5 to 95% (non-condensing); 0 to 10,000 ft. altitude
Dimensions
0.83"H x 1.80"W x 3.35"D (2.11 x 4.57 x 8.51 cm)
4
