The DIN clips are designed for use on a DIN-35 rail.
Powering the IE-MiniMc
The IE-MiniMc includes multiple powering options:
•
A country-specific, high-reliability AC power adapter (included)
•
The IEEE 802.3af Power over Ethernet standard; draws power from power
sourcing equipment
•
The 4-terminal DC power block
•
IE-PowerTray/18 for Rack Mounting
About Power Over Ethernet (PoE) and IE-MiniMc
Power Over Ethernet technology allows the IE-MiniMc to be a Powered Device (PD)
and draw power when connected to Power Sourcing Equipment (PSE). Power
Sourcing Equipment distributes an electrical current across existing copper data
cabling.
LED Operation
Each IE-MiniMc includes two LEDs, located on the RJ-45 connector.
LED functions are as follows:
FX LNK/ACT
Glows green when a link is established on the fiber port; blinks green
when activity is detected on the fiber port.
TX LNK/ACT
Glows amber when a link is established on the copper port; blinks
amber when activity is detected on the copper port.
NOTE
