- SEQ OUT (Sequencer Output Assign)
Specify the output destination from the sequencer to the
sound source.
Range:
- INT: Output to the internal sound generator.
- EXT: Output to the MIDI OUT connector.
- BOTH: Output to both of the above simultaneously.
When these settings windows are displayed, each of the
settings can be made using the assignable knobs 1-4.
- When Part R, 1, 2, or 3 is selected:
The assignable knobs 1-4 are used for setting Parts R and
1-3, respectively.
- When Part 4, 5, 6, or 7 is selected:
The assignable knobs 1-4 are used for setting Parts 4-7,
respectively.
On the MC-307, the following parameters are saved
for each pattern.
These parameters are collectively referred to as the
"Setup parameters."
- Standard Tempo (P. 18)
- Patch/Rhythm Set Number * (P. 21)
- LEVEL * (P. 22)
- PAN * (P. 22)
- KEY SHIFT* (P. 22)
- REVERB LEVEL * (P. 22)
- DELAY LEVEL * (P. 22)
- M-FX SWITCH * (P. 22)
- SEQ OUT * (P. 23)
- REVERB settings (P. 42)
- DELAY settings (P. 44)
- M-FX settings (P. 46)
- Part Mute status * (P. 19)
- Rhythm Mute status (P. 19)
The "*" indicates parameters that are set
independently for each part.
Chapter 2 Basic of Pattern Playback

Saving a Pattern

When you have made the settings for patches used for a
pattern and the mute mode, save the pattern as a user
pattern.
Unless saved, the data for any recorded or edited Pattern is lost
when the power is turned off.
Procedure
Stop operation if the pattern is being played back or
recorded.
1. Press [SYSTEM] button.
2. Press [F3 (WR)] button.
3. Press [F3 (PTN)] button.
The screen for specifying the pattern to be saved and the
destination pattern appears.
The pattern is saved under the pattern number selected
here. Care is needed when selecting an appropriate
pattern number since the pattern previously saved under
that name is deleted.
4. Press [F4 (WR)] button.
The pattern naming screen appears.
5. Use [VALUE]dial or [INC/DEC]button to specify
characters.
The following characters are available.
space, A–Z, a–z, 0–9,! " # $ % & ' ( ) * +, - . / : ; < = > ? @
[ \ ] ^ _ ` { | }
6. After characters have been specified, press [F4 (OK)]
button.An "ARE YOU SURE?" message appears.
7. Press [F4 (EXEC)] button.
SAVE operation is executed.
* In step 5 above, upper-case or lower-case versions of the
selected characters can be specified by pressing [CURSOR
(up/down)] buttons.
* In step 5, [F1] and [F2] buttons can be conveniently used for
editing the name.
- [F1 (INS)]: Press to insert a character at the cursor
position.
- [F2 (DEL)]: Press to delete the character at the cursor
position.
