Owner's Manual
Thank you, and congratulations on your choice of the Roland MC-909 Sampling Groovebox.
201b
Before using this unit, carefully read the sections entitled: "IMPORTANT SAFETY INSTRUCTIONS"
(Owner's Manual p. 2), "USING THE UNIT SAFELY" (Owner's Manual pp. 3–4), and "IMPORTANT
NOTES" (Owner's Manual p. 5). These sections provide important information concerning the
proper operation of the unit. Additionally, in order to feel assured that you have gained a good
grasp of every feature provided by your new unit, Quick Start and Owner's Manual should be read in
its entirety. The manual should be saved and kept on hand as a convenient reference.
Convention Used in This Manual
• Words enclosed in square brackets indicate buttons or a dial or a knob or a slider on the panel.
• (p. **) indicates a reference page.
985
* The explanations in this manual include illustrations that depict what should typically be shown by the
display. Note, however, that your unit may incorporate a newer, enhanced version of the system (e.g., includes
newer sounds), so what you actually see in the display may not always match what appears in the manual.
202
Copyright © 2002 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the
written permission of ROLAND CORPORATION.
