Roland MC-808 Attachment Manual

Attaching the Ferrite Core

All rights reserved. No part of this publication may be reproduced in any form
You must attach the ferrite core before using the USB cable.
If you use a USB cable to connect the MC-808 to your computer, you must attach
the included ferrite core.
This is for the purpose of preventing electromagnetic interference; do not
remove it.
* Use only the ferrite core that are supplied with the MC-808.
1. Attach the ferrite core to the USB cable.
* Make sure to attach it near the plug on the end that connects to the MC-808.
Computer
2. Press the halves together until they click shut.
* If the USB cable is thin, the attached ferrite core may slide along the cable. If so,
use a band or adhesive tape to fasten the ferrite core in place. One such band is
included.
Band for fastening the core
* Be careful not to pinch your fingers when attaching the ferrite core.
* Do not damage the cable by pinching it excessively with the ferrite core.
Copyright ©2006 ROLAND CORPORATION
without the written permission of ROLAND CORPORATION.
Ferrite core
USB cable
MC-808
