Attaching The Waste Chip Box; Storing The Accessory Box; Standard Accessories - Janome CompuLock Instruction Book

2
1
1
2
6 7 8
11
14
13
1
2
3
4
5
9
10
12
15

Attaching the Waste Chip Box

Press the waste chip box against the looper
cover and slide it to the left until the pin on the
waste chip box slides into the hole on the side
plate, as illustrated.
1 Waste chip box
2 Pin

Storing the Accessory Box

Insert the accessory box into the waste chip box.
1 Waste chip box
2 Accessory box

Standard Accessories

1 Nets
2 Spool caps
3 Set of needles
4 Upper knife
5 Spreader
6 Screwdriver (large)
7 Screwdriver (small)
8 Tweezers
9 Lint brush
10 Spanner/wrench
11 Oil
12 Needle threader
13 Needle plate (B) for Cover Stitch
14 Presser foot (B) for Cover Stitch
15 Extension table (B)
4
