" For appliances with a polarized plug (one blade
wider than the other).
To reduce the risk of electric shock, this plug is intended
to fit in a polarized outlet only oneway.
If the plug does not fit fully in the outlet, reverse the
plug.
If it still does not fit, contact a qualified electrician to
install the proper outlet.
Do not modify the plug in anyway."
* Foot control Model 21371 for use with Sewing
Machine Model 888(Compulock)
(For U.S.A. market only.)
8

SECTION 2 OPERATING INSTRUCTIONS

1
4
3
7
6
2
5

Plug in the Machine and Switch on Power

Before connecting the power supplycord,
make sure the voltage and frequency shown
on the machine conform to your electrlcal
power.
For Your Safety
* While in operation, always keep your eye on
the sewing area,and do not touch any mov-
ing parts such as the upper looper, handwheel,
needle or knives.
* Always disconnect the machine from the
power supply:
When leaving the machine unattended.
When attaching or removing parts.
When threading or cleaning the machine.
* Do not place anything on the foot control,
except when in use.

To Sew Using Foot Control

1 Turn off the power switch. Connect the foot
control plug and the machine plug into to the
machine socket.
2 Connect the power supply plug to your
power supply.
1 Power switch
3 Machine plug
5 Power supply plug
7 Power supply cord

Controlling Sewing Speed

Sewing speed can be varied by the foot
control.The harder press on the foot control,
the faster the machine runs.
Note:
* The Compulock is equipped with a protective
circuit to prevent overheating.
The machine will stop automatically if it is
running overloaded for a long time.
In such a case, follow the message that
appears on the visual touch screen.
There are five motors for thread tension ad-
justment inside the machine which make a bit
of noise intializing when first turned on.
This sound is perfectly normal and does not
indicate a malfunction.
5
2 Foot control plug
4 Machine socket
6 Power supply
8 Foot control
