SECTION 1 PREPARATION

15
14
18
3

Names of Parts

1 Visual touch screen
2 Thread guide indication
3 Pressure adjusting dial
4 Screen sharpness adjusting knob
5 Up/Down needle position key
11
6 Side cover
10
7 Looper cover
8 Handwheel
9 Power switch
10 Differential feed dial
9
11 Stitch length dial
8
12 Extension table (A)
13 Double chain looper
14 Lower looper
13
15 Upper looper
16 Upper knife
17 Chaining finger setting knob
18 Presser foot
19 Needle plate
20 Cutting width adjusting dial
21 Upper knife release knob
