2
OPERATION

D TX code channel selection

If the transcever has a [TX CH] key, the dsplay can be tog-
gled between the operatng channel number (or name) and
TX code channel number (or name). When the TX code chan-
nel number (or name) s dsplayed, the [
the TX code channel.
To select a TX channel:
q Push [TX CH]—a TX code channel appears.
w Push [ ]/[ ] to select the desred TX code channel.
e After selectng, push [TX CH] to set.
• Returns to the stand-by mode.
r Push [CALL] to transmt the selected TX code.

D TX code number selection

If the transcever has a [TX CH] key, TX code contents can
be changed wthn the allowable dgts.
To select a TX code:
q Push [TX CH]—a TX code number appears and the first
dgt blnks.
w Push [ ]/[ ] to select the desred number of the blnk-
ng dgt.
e Push [TX CH] to enter the selected number and the next
dgt wll start blnkng automatcally.
r Repeat step w and e to nput all allowed dgts.
t Push [CALL] to transmt the selected TX code.
9

D DTMF transmission

If the transcever has a [DTMF] key, the automatc DTMF
transmsson functon s avalable. Up to 7 DTMF channels
may be avalable.
]/[ ] keys select
To transmit a DTMF code:
q Push [DTMF]—a DTMF code channel appears.
w Push [
e Push and hold [DTMF] to transmt the DTMF code on the
selected DTMF channel.

D Scrambler function

The UT-109 (#02) or UT-110 (#02) optonal voce scrambler
unt provdes hgh performance prvate communcaton be-
tween statons wth the same scrambler codes.
To turn the scrambler function ON and OFF:
q Push and hold [SCRM] to turn the scrambler functon ON.
w Push [SCRM] to turn the functon OFF.
]/[ ] to select the desred DTMF channel.
