Field Controls Eliminator EL-1 Instruction Manual page 3

ELECTRICAL DATA
VOLTS AMPS HZ WATTS RPM THERMAL OR IMPEDANCE PROTECTION
120 VAC .60 60 35 3000 YES
A permanent wiring method must be used for power connection. It is recommended that a minimum size of
14 AWG wire for electrical supply connections and wiring should be suitable for 60 C (180 F) temperature.
O O
The ELIMINATOR™ should be wired with an over current protection device (fuse or circuit breaker) rated 15
amperes or less. Wiring method should be in accordance with the National Electrical Code and any local
code requirements.
WIRING (See Figures 5 & 6)
Figure 5
Figure 6
