System Map: Front View

1. Optional Built-In PC Camera
2. LCD (With Optional Touch Panel - see page
7 - 23)
3. Power & System Activity LED Indicators
4. Function Buttons*
5. Power Button*
6. USB 2.0 Ports
7. Microphone-In Jack
8. Headphone/Speaker-Out Jack
9. RJ-45 LAN Jack
10. 2 * USB Ports
11. eSATA Port
12. External Monitor Port
13. 2 * COM Ports
14. DC-In Jack
3
11
9
10
4
5
6
8
7
14
13 13
12
Figure 1 - 2 - Front View
1
2
3 4
6
*Note the power and function buttons are located
along the bottom of the LCD
System Map: Front View 1 - 5
