Replacing the Component Bay Cover

1. Make sure latch is in the unlocked (i.e. slide to the left towards the unlocked
1
symbol) position (otherwise the cover cannot be properly reinserted).
2. Press the cover firmly down with you hand, as illustrated, to insure the cover is in
place.
3. Align the markers on the case
direction of arrow
3
2
2
and cover first, and then slide the cover in the
2
until it clicks into place.
1
3
Upgrading The Computer
2
Replacing the Component Bay Cover 6 - 7
Figure 6 - 4
Component Bay
Cover Insertion
