Figure 6 - 4
Replacing the
Component Bay
6
Cover
(Model A)

6 - 6 Replacing the Component Bay Cover - Model A

Replacing the Component Bay Cover - Model A
1. Reinsert the component bay cover by placing it on the bottom case assembly,
applying downward pressure and by sliding it on to the case in the direction of
arrow .
1
2. Make sure the case markers
3. Replace screws -
1
2
line up.
2
(Figure 6 - 2 on page 6 -
3
2
4) and battery (see page 6 -
1
3).
