Introduction
Interface
Two USB 3.0 Ports
Two USB 2.0 Ports (Note one USB 2.0 port can supply power
when the system is off but still powered by the AC/DC adapter)
One eSATA & USB 2.0 Combo Port
One HDMI-Out Port
One DVI-Out Port
One IEEE1394a Port
One S/PDIF-Out Jack
One Headphone/Speaker-Out Jack
One Microphone-In Jack
One Line-In Jack
One RJ-45 LAN Jack
One DC-In Jack
Note: External 7.1CH Audio Output Supported by Headphone,
Microphone, Line-In and S/PDIF-Out Jacks
Mini Card Slots
Slot 1 for WLAN Module or Combo WLAN and Bluetooth
Module
(Factory Option) Slot 2 for 3.75G/HSPA Half Mini-Card Mod-
ule
Environmental Spec
Temperature
° °
Operating: 5 C - 35 C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%

Overview 1 - 3
