EUROCOM TN120T Service Manual page 16

Introduction
Feature
Card Slots
Communication
*
Note: The 3.5G
and Intel
Memory
cannot coexist. If one
of these factory op-
tions is included in
your purchase op-
tion, then the other is
unavailable.
Power
Management
Power
Battery
Environmental
Spec
Operating
Systems
Supported
Dimensions
& Weight
1 - 4 System Specifications
One ExpressCard/34(54) Slot
One MiniCard Slot Supporting USB and PCIe Interfaces for WLAN Module
Second MiniCard Slot Supporting USB and PCIe Interfaces for Intel® Turbo Memory Module OR 3.5G Module
56K Plug and Play Fax Modem
10M/ 100M/ 1000M Base-TX Ethernet LAN
Wireless LAN Module Options:
Turbo
802.11 b/g Half Mini-Card USB Wireless LAN Module (Option)
Modules
Intel® WiFi Link 5300 Series (3*3 - 802.11a/g/n) PCie Wireless LAN Half Mini-Card Module
(Option)
Intel® WiFi Link 5100 Series (1*2 - 802.11a/g/n) PCie Wireless LAN Half Mini-Card Module
(Option)
1.3M or 2.0M Pixel USB PC Camera Module (Factory Option)
Bluetooth V2.1 + EDR (Enhanced Data Rate) Module (Factory Option)
*
UMTS/HSPDA-based 3.5G Module with MiniCard Interface (Factory Option)
Quad-band GSM/GPRS (850 MHz, 900 MHz, 1800 MHz, 1900 MHz)
UMTS WCDMA FDD (2100 MHz)
Supports ACPI 3.0
Supports Wake on LAN
Full Range AC/DC Adapter AC input 100 - 240V, 50 - 60Hz, DC Output 19V, 3.42A or 18.5V, 3.5A (65 Watts)
4 Cell Smart Lithium-Ion Battery Pack, 14.8V/2.4AH
8 Cell Smart Lithium-Ion Battery Pack, 14.8V/4.4AH (Option)
Temperature
Operating: 5 °
Non-Operating: -20°C ~ 60°C
Windows® Vista 32-bit (with Service Pack 1)
Windows® XP (with Service Pack 3)
306mm (w) * 224mm (d) * 35 - 37.5mm (h)
Specification
Supports Resume from Modem Ring
Relative Humidity
C ~ 35 ° C Operating:
Non-Operating:
2.1 kg With 4 Cell Battery and ODD
UMTS Modes
Note that UMTS
modes CAN NOT
be used in North
America.
20% ~ 80%
10% ~ 90%
