Change the output volume level (audio models only)

Users can set each output's volume level through a range of zero steps of
attenuation (full attenuation, minimum volume) to 64 steps of attenuation (no
attenuation, full volume) from the RGB and Audio Settings page.
Change an output's audio level setting as follows:
1. Click the output drop box. A drop down scroll box appears (figure 6-18).
Figure 6-18 — Output selection drop box
2. Click and drag the slider or click the scroll up
button until the desired output is visible.
3. Click the desired output.
4. Click the Volume Steps (64 Max) drop box. A drop down scroll box appears
(figure 6-19).
Figure 6-19 — Volume drop box
5. Click the desired output volume step value.
The table on the next page defines the value of each audio volume step.
CrossPoint 450 Plus and MAV Plus Switchers • HTML Operation
button or scroll down
6-17
