Matrix 3200/6400 Video Switcher Specifications

Video input

Number/signal type ............... Up to 32 or 64 (varies with configuration) RGsB, RsGsBs, component video,
Connectors ........................... BNC female (quantity varies with model)
Nominal level ....................... Analog ...... 1V p-p
Minimum/maximum level(s) ... Analog ...... 0.5V to 1.5V p-p
Impedance ........................... 75 ohms
Return loss ........................... –30dB @5 MHz
External sync (genlock) ........ 0.3V to 12V p-p, 75 ohms
Video throughput
Routing ................................. 16 x 8 or larger matrix up to 32 x 32 or 64 x 64, depending on model and
Gain ..................................... Unity
Bandwidth — Matrix 6400 .... Minimum .............. 80 MHz (–3dB), fully loaded
Crosstalk .............................. > 65dB @ 20 MHz
Switching speed ................... 200 nS (max.)

Video output

Number/signal type .............. Up to 32 or 64 (varies with configuration) RGsB, RsGsBs, component video,
Connectors ........................... BNC female (quantity varies with model)
Nominal level ....................... 1V p-p
Impedance ........................... 75 ohms
Return loss ........................... –40dB to input section 3.58 MHz/4.43 MHz
DC offset .............................. ±10mV maximum
Switching type ...................... Vertical interval
Slew rate .............................. >200V/mS
Control/Remote — switcher
Serial control port ................. RS-232 or RS-422, 9-pin female D connector
Baud rate and protocol ......... 9600 , 8-bit, 1 stop bit, no parity
Pin configurations ................. 2 = TX, 3 = RX, 5 = GND
System intercommunications 2 RJ-11 connectors
Remote keypad control ......... 2 5 mm, 5-pin captive screw connectors
Program control .................... Extron's control program for Windows®
General
Power ................................... 100VAC to 240VAC, 50/60 Hz; internal, auto-switchable
Matrix 6400 video ........ 90 watts at 115VAC, 60 Hz
Matrix 3200 video ........ 40 watts at 115VAC, 60 Hz
Temperature/humidity ........... Storage –40° to +158° F (–40° to +70° C) / 10% to 90%, non-condensing
Rack mount .......................... Yes
Enclosure type ..................... Metal
1-7
Chapter 1 • Introduction to the Matrix 3200/6400 Video Switcher
S-video, composite video, HDTV
configuration
Maximum ............. 150 MHz (-3dB), fully loaded
0–10 MHz............. No more than +0.1dB to -0.1dB
0–30 MHz............. No more than +0.5dB to -0.5dB
> 80dB @ 60 MHz
S-video, composite video, HDTV
Extron's Simple Instruction Set™ — SIS™
Operating +32° to +122° F (0° to 50° C) / 10% to 90%, non-condensing
